Eaton PBP6 Push Button Enclosures - NEMA 12 Rated
Part Number: PBP6
Quick Summary
Eaton PBP6 push button enclosures provide durable, surface-mounted housing for control stations in demanding industrial environments. Maintenance crews wrestle with protecting sensitive controls from dust, moisture, and oil leaks in tight spaces. Key standards include a NEMA 12 rating with carbon steel construction and an oil-resistant gasket, made in the US for traceability. For installers and procurement teams, the PBP6 supports surface mounting with external feet and a hinged cover to speed commissioning. Its 11 inch by 6 inch by 7.5 inch footprint balances enclosure capacity with footprint control, while the 14 gauge carbon steel wall resists deformation in busy plant floors. Users gain predictable performance under typical automation workloads, with reduced downtime and simpler parts sourcing across Eaton’s B-Line series.
Product Information
Extended Description
PBP6 Eaton: Eaton B-Line series push button enclosures, 11" height, 7.5" length, 6" width, NEMA 12, Hinged cover, PBP enclosure, Surface mounted, Medium single door, External mounting feet, Carbon steel, Oil-resistant gasket
Product Name
Eaton B-Line series push button enclosures
Catalog Number
PBP6
UPC
782051702125
Product Length/Depth
7.5 in
Product Height
11 in
Product Width
6 in
Product Weight
10.7 lb
Compliances
Not Applicable
Certifications
Not Applicable
Material
Carbon steel
Wall thickness
14 gauge
Finish color
Painted
Color
ANSI 61 gray
Style
Medium single door
Model
PBP enclosure
Cover type
Hinged
Mounting method
Surface
Mounting hole details
External mounting feet
Closure type
Hinged
Special features
Removable cover, recessed pull ring, plated screws
NEMA Rating
12
Country of origin
US
Feature → Business Impact → Application: Carbon steel construction with 14 gauge wall delivers rugged durability for heavy-duty industrial environments, reducing panel damage and extending service life in machine rooms and production lines. This supports a lower total cost of ownership for control panels and safety enclosures in automotive, food & beverage, and packaging facilities. Feature → Business Impact → Application: NEMA 12 protection provides dust and non-oil-based liquid ingress resistance, ensuring reliable operation in dusty conveyors and wash-down-adjacent areas without introducing costly seals or frequent replacements. Feature → Business Impact → Application: Removable cover, recessed pull ring, and plated screws simplify maintenance, enabling faster field inspections and module upgrades in automation cell enclosures. Feature → Business Impact → Application: Hinged cover and external mounting feet enable rapid commissioning and flexible installation for surface-mounted control housings in legacy lines and new builds. Feature → Business Impact → Application: ANSI 61 gray painted finish enhances corrosion resistance and aesthetics in indoor industrial spaces, supporting consistent branding and inspector visibility for audit-ready enclosures. Feature → Business Impact → Application: External mounting feet allow stable, vibration-tolerant mounting on various surface substrates, reducing reinstallations and improving long-term alignment of push-button operator stations.
Get a Quick Quote for a Eaton PBP6
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton PBP6?
Enquire Now
FAQs
The PBP6 is a surface-mounted, medium single-door enclosure with external mounting feet and a hinged cover. Plan for a flat mounting surface and ensure access for the hinged door. Recessed pull ring and plated screws simplify service, while external feet support stable anchoring on varied floor substrates. Consider clearances for the door swing and cable entries to maintain easy maintenance access.
PBP6 features a 11 in height, 7.5 in depth, and 6 in width footprint, with a 14 gauge carbon steel wall and oil-resistant gasket. It carries a NEMA 12 rating for indoor dust and light washdown protection, and weighs about 10.7 lb. The enclosure is painted ANSI 61 gray and designed for external mounting with hinged closure.
Yes. The PBP6 is designed for control stations and automation panels in manufacturing and processing facilities. Its rugged carbon steel body, NEMA 12 protection, and removable cover simplify enclosure access, while surface mounting and external feet speed installation in existing lines. The combination supports reliable operation in busy production floors with reduced downtime during upgrades.
PBP6 lists a NEMA Rating of 12 and US country of origin, with Compliances and Certifications marked as Not Applicable in the provided data. It uses a carbon steel 14 gauge wall and oil-resistant gasket for environmental protection. For projects requiring CE or UL, verify with the supplier or Eaton’s official specifications for any updated certifications.
Deployment benefits include longer service life from rugged 14 gauge carbon steel, reduced maintenance due to removable cover and accessible hardware, and faster commissioning with external mounting feet. These factors translate to lower downtime, fewer field trips for repairs, and improved asset reliability across automation cabinets and control stations.
