Eaton PRL1X1225X30C Pow-R-Xpress Panelboard - UL 67 225A
Part Number: PRL1X1225X30C
Quick Summary
The Eaton PRL1X1225X30C panelboard provides compact 120/240V power distribution for commercial and light industrial applications, combining robust protection with streamlined installation. Engineers often struggle with space constraints, compatibility challenges, and long lead times when upgrading existing electrical panels. UL 67 certification, NEMA compliance, and copper bus construction ensure reliable operation, safer disconnection, and sustained performance in demanding environments. With a 225 A rating, 30 circuits, and interior mounting designed for fast field assembly, this Pow-R-Xpress panelboard reduces commissioning time and supports scalable expansions while meeting strict safety and energy-management requirements.
Product Information
Extended Description
PRL1X1225X30C Eaton: Eaton PRL1X INTERIOR 120/240V 1P 3W 225A 30 CKT CU BUS
Product Name
Eaton Pow-R-Xpress PRL1X panelboard
Catalog Number
PRL1X1225X30C
UPC
786689362959
Product Length/Depth
37 in
Product Height
6 in
Product Width
15 in
Product Weight
96 lb
Compliances
NEMA Compliant
Certifications
UL 67
Bus material
Copper
Number of circuits
30
Type
PRL1X INTERIOR
Amperage Rating
225 A
Pow-R-Xpress stocking program flyer
Pow-R-Xpress stocking program flyer
Pow-R-Xpress stocking program flyer
Pow-R-Line Xpert family overview
Eaton Specification Sheet - PRL1X1225X30C
Feature: Compact interior footprint enables space-constrained installations to accommodate 120/240V single-phase distribution with 30 circuits in a 225 A frame. Business Impact: Reduces floor space needs, simplifies bus routing, and lowers total installed cost. Application: Office buildings, data centers, light manufacturing lines, and retrofit projects. Feature: Copper bus construction and robust amperage rating support high-current distribution with low resistance. Business Impact: Improves voltage regulation, minimizes voltage drop, and enhances fuse coordination for critical circuits. Application: Main distribution in commercial spaces and equipment rooms needing reliable power paths. Feature: UL 67 listing and NEMA compliance provide documented safety and code conformance. Business Impact: Accelerates approvals, reduces redlines, and streamlines procurement workflows. Application: Facilities with strict regulatory and inspector requirements. Feature: 1P 3W interior configuration simplifies wiring and breaker selection for single-phase service. Business Impact: Shortens installation time, reduces training needs, and lowers maintenance complexity. Application: Small to mid-size electrical rooms and retrofit installations. Feature: Precise dimensions and weight (37 in depth, 15 in width, 6 in height, 96 lb) enable easier handling and fit within standard enclosures. Business Impact: Facilitates transport, site planning, and compatibility with existing infrastructure. Application: Retrofit projects in constrained spaces and modular building layouts. Feature: Availability of specification sheets and brochures supports rapid procurement and accurate scoping. Business Impact: Improves sourcing accuracy, reduces order errors, and accelerates project timelines. Application: Procurement teams, engineers, and system integrators seeking validated data.
