Eaton PV4M-4XS Push Button Enclosures - NEMA 4X
Part Number: PV4M-4XS
Quick Summary
Eaton PV4M-4XS Push Button Enclosures protect control circuits in rugged industrial panels and control cabinets. When wiring and maintenance happen in wet, dirty, or cramped environments, limited access and corrosion risk slow projects. With a NEMA 4X rating, US origin, and 304 stainless steel construction, these enclosures resist moisture, chemicals, and impact. This surface-mounted solution, featuring a removable screw-cover, provides long service life and easy access for routine maintenance, while offering a compact 10.25 in height and 3.25 in width that fits tight control panels.
Product Information
Extended Description
PV4M-4XS Eaton: Eaton B-Line series push button enclosures, 10.25" height, 2.75" length, 3.25" width, NEMA 4X, Screw cover, PVM4XS enclosure, Surface mounted, Medium single door, External mounting feet, 304 stainless steel, Oil-resistant gasket
Product Name
Eaton B-Line series push button enclosures
Catalog Number
PV4M-4XS
UPC
782051138177
Product Length/Depth
2.75 in
Product Height
10.25 in
Product Width
3.25 in
Product Weight
4.1 lb
Compliances
Not Applicable
Certifications
Not Applicable
Material
304 stainless steel
Wall thickness
14 gauge
Finish color
#4 brushed
Color
Gray
Style
Medium single door
Model
PVM4XS enclosure
Cover type
Screw
Mounting method
Surface
Mounting hole details
External mounting feet
Special features
Removable cover, recessed pull ring, s.s. screws
NEMA Rating
4X
Country of origin
US
Feature: 304 stainless steel construction with 14 gauge wall and oil-resistant gasket. Business Impact: Excellent corrosion resistance and enduring durability in washdown and chemical-exposure environments, reducing replacement and downtime. Application: Food processing, water treatment, and outdoor industrial panels benefit from long service life. Feature: NEMA 4X rating. Business Impact: Provides superior protection against water, dust, and chemical intrusion, enabling reliable operation in harsh environments and simplifying compliance with harsh-environment requirements. Application: Outdoor enclosures and washdown areas in manufacturing plants.Feature: Surface mounting with external mounting feet. Business Impact: Fast, secure installation with flexible mounting options, minimizing installation time and enabling clean, accessible control housing layouts. Application: Machine and panel installations where wall or surface mounting is preferred.Feature: Removable cover, recessed pull ring, and stainless steel screws. Business Impact: Quick access for maintenance and inspections without sacrificing security, lowering maintenance labor costs. Application: Routine door access for controls, operators, and test points in demanding facilities.Feature: Medium single door design with PVM4XS enclosure model and screw cover. Business Impact: Compact footprint fits tight control spaces while maintaining secure enclosure integrity. Application: Control stations and local control panels in compact machine layouts.
Get a Quick Quote for a Eaton PV4M-4XS
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton PV4M-4XS?
Enquire Now
FAQs
PV4M-4XS supports surface mounting with external mounting feet, enabling quick installation on walls or machinery frames. The design suits tight spaces by providing a compact footprint (10.25 in height, 3.25 in width) while ensuring stable, vibration-resistant mounting in industrial environments. This makes integration straightforward in conveyors, presses, and control panels.
PV4M-4XS uses 304 stainless steel with a 14 gauge wall and an oil-resistant gasket, delivering superior corrosion resistance and chemical resistance. Its NEMA 4X rating protects against water, dust, and washdown debris, reducing maintenance frequency and extending service life in plants, food processing, and outdoor installations.
Yes. The PV4M-4XS enclosure is designed with external mounting feet to simplify installation on walls and frames. This feature provides flexible placement options, improves accessibility for wiring and maintenance, and supports robust mounting in space-constrained control panels and industrial cabinets.
PV4M-4XS carries a NEMA 4X rating, indicating strong protection against moisture, dust, and corrosion. It is manufactured in the US and uses 304 stainless steel with an oil-resistant gasket. The data does not list CE, SIL, or IP certifications, so focus on NEMA 4X compatibility and US-origin construction for regulatory considerations.
The enclosure features a removable screw-cover and a recessed pull ring for quick door access, reducing maintenance time. Its stainless steel construction and gasket design deliver long-term durability in demanding environments, lowering replacement frequency and downtime while enabling easier inspections and preventive maintenance on control panels.
