Eaton PV4MF JIC Enclosure - NEMA 4X Fiberglass
Part Number: PV4MF
Quick Summary
The Eaton PV4MF JIC Enclosure protects electrical panels in harsh environments with a fiberglass, NEMA 4X-rated housing. Installation complexity, moisture ingress, and corrosion are common headaches in rugged facilities, and this unit simplifies mounting and sealing. Certified to UL 50 and CSA C22.2 standards for rugged safety, with NEMA 4X rating for water and dust resistance. Designed for surface-mounted installations and PVMF-style configurations, it delivers maintenance-friendly access and extended service life, lowering total cost of ownership. Compatible with standard PVMF accessories and fiberglass construction for corrosion resistance in rugged industrial sites. Manufacturers will appreciate easy sourcing of spares and straightforward field servicing.
Product Information
Extended Description
PV4MF Eaton: Eaton B-Line series JIC panel enclosure, 8.88" height, 3.89" length, 3.81" width, NEMA 4X, Screw cover, PVMF enclosure, Surface mounted, Medium single door, No mounting provisions, Fiberglass, Seamless poured in-place gasket
Product Name
Eaton B-Line series JIC panel enclosure
Catalog Number
PV4MF
UPC
782051537970
Product Length/Depth
3.89 in
Product Height
8.88 in
Product Width
3.81 in
Product Weight
2 lb
Certifications
UL 50 NEMA CSA C22.2.
Material
Fiberglass
Finish color
Unfinished
Color
Gray
Style
Medium single door
Model
PVMF enclosure
Cover type
Screw
Mounting method
Surface
Mounting hole details
No mounting provisions
NEMA Rating
4X
Country of origin
US
Fiberglass construction delivers corrosion resistance and non-conductive protection. This reduces maintenance costs and extends service life. The enclosure is ideal for outdoor panels in chemical plants, mining operations, and wastewater treatment. UL 50 and CSA C22.2 certified, with a NEMA 4X rating, delivering reliable weather sealing and regulatory alignment for rugged environments. A seamless poured-in-place gasket and screw cover provide proven ingress protection while keeping service access straightforward, minimizing moisture intrusion during wet or humid operations. Surface mounting with no internal mounting provisions offers flexible integration with existing frames or PVMF accessories, simplifying retrofits and reducing installation planning time. At 8.88 in height, 3.89 in depth, and 3.81 in width, weighing 2 lb, the PV4MF is easy to handle and install in constrained spaces. The gray, unfinished fiberglass supports field coatings or dealership color customization.
Get a Quick Quote for a Eaton PV4MF
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton PV4MF?
Enquire Now
FAQs
PV4MF is designed for surface mounting and does not include internal mounting provisions. This approach provides flexible integration with existing frames and PVMF accessories, making retrofits straightforward. For new installations, consider mounting to a compatible surface or support frame and seal the panel using the seamless gasket and screw cover to maintain NEMA 4X protection.
Yes. The PV4MF features fiberglass construction and a NEMA 4X rating, reinforced by UL 50 and CSA C22.2 certifications. This combination delivers robust weather sealing, corrosion resistance, and reliability in outdoor, dusty, or chemically challenging settings such as outdoor switchgear, chemical plants, and mining facilities.
The enclosure measures 8.88 inches in height, 3.89 inches in depth, and 3.81 inches in width, with a stated weight of 2 pounds. These compact dimensions enable easy handling, shipping, and installation in space-constrained control rooms or equipment housings.
PV4MF carries UL 50 and CSA C22.2 certifications and a NEMA 4X rating, confirming suitability for harsh environments. These certifications support compliance with industrial safety and reliability standards, helping to reduce risk during audits and deployments in regulated facilities.
The fiberglass construction resists corrosion, reducing maintenance frequency and extending service life. The seamless gasket and screw cover minimize ingress and service disruption, while surface mounting and compatibility with PVMF accessories streamline retrofits. Together, these factors lower downtime, spare part usage, and total cost of ownership over the enclosure’s life cycle.
