Eaton PV6MF Panel Enclosure - Fiberglass JIC, NEMA 4X
Part Number: PV6MF
Quick Summary
Eaton PV6MF panel enclosure protects control gear in harsh industrial environments. Engineers often battle moisture ingress, limited mounting space, and maintenance access challenges during panel upgrades. UL 50, CSA C22.2, and NEMA 4X ratings provide reliable safety and regulatory confidence for indoor and outdoor installations. The fiberglass construction and surface-mount design reduce weight and installation time, while delivering durable protection. This combination supports faster project timelines, lower lifecycle costs, and improved reliability for facilities requiring robust, code-compliant enclosures.
Product Information
Extended Description
PV6MF Eaton: Eaton B-Line series JIC panel enclosure, 11.13" height, 3.89" length, 3.81" width, NEMA 4X, Screw cover, PVMF enclosure, Surface mounted, Medium single door, No mounting provisions, Fiberglass, Seamless poured in-place gasket
Product Name
Eaton B-Line series JIC panel enclosure
Catalog Number
PV6MF
UPC
782051537994
Product Length/Depth
3.89 in
Product Height
11.13 in
Product Width
3.81 in
Product Weight
3 lb
Certifications
UL 50 NEMA CSA C22.2.
Material
Fiberglass
Finish color
Unfinished
Color
Gray
Style
Medium single door
Model
PVMF enclosure
Cover type
Screw
Mounting method
Surface
Mounting hole details
No mounting provisions
NEMA Rating
4X
Country of origin
US
The PV6MF enclosure uses fiberglass construction to resist corrosion and chemical exposure, delivering long-term reliability in harsh environments with minimal maintenance. This translates to lower replacement costs and fewer field service events for control panels exposed to humidity, dust, or outdoor elements. Its surface mounting and medium single door with a screw cover simplify installation and field servicing, enabling quick retrofits and faster commissioning in compact spaces. The seamless poured-in-place gasket enhances ingress protection, reducing air and water leakage and supporting strict NEMA 4X compliance for both indoor and outdoor applications. Weighing just 3 lb with dimensions of 11.13 in height, 3.89 in length, and 3.81 in width, the PV6MF delivers a compact footprint for crowded control rooms and equipment bays. The model’s “no mounting provisions” design is offset by practical surface mounting advantages, improving compatibility with the PVMF enclosure family and other B-Line components. The product's UL 50 and CSA C22.2 certifications reinforce safety and regulatory alignment when integrating with customer electrical systems, while the unfinished gray finish accepts field painting to match site color standards. This combination supports quick, code-compliant installations with minimal specialty tooling and reduced commissioning risk, enabling facilities to meet demanding uptime and safety requirements.
Get a Quick Quote for a Eaton PV6MF
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton PV6MF?
Enquire Now
FAQs
PV6MF is designed for surface mounting and pairs with Eaton B-Line series enclosures. It features no internal mounting provisions, so it complements surface-mounted PVMF enclosures and similar wall-mounted configurations. Use compatible mounting screws and gasket seals to maintain NEMA 4X integrity during retrofits and new installations.
PV6MF measures 11.13 in high, 3.89 in deep, and 3.81 in wide, weighing 3 lb. It is a fiberglass, gray, unfinished enclosure with a screw cover and a medium single door. It carries UL 50, NEMA 4X, and CSA C22.2 certifications, and uses a seamless poured-in-place gasket for reliable ingress protection.
Yes, PV6MF is suitable for outdoor and damp indoor environments due to its NEMA 4X rating, reinforced by UL 50 and CSA C22.2 standards. The fiberglass construction offers corrosion resistance, while the gasket and screw cover help maintain enclosure integrity when exposed to weather and contaminants.
The screw cover enables straightforward access for maintenance while preserving enclosure integrity. The seamless gasket minimizes ingress paths, supporting regulatory compliance for control panels in harsh environments. The combination of UL 50, CSA C22.2, and NEMA 4X certifications provides documented safety and performance for code-conscious facilities.
The PV6MF reduces maintenance events through corrosion resistance, a lightweight design for easier installation, and a durable fiberglass body that withstands harsh environments. These factors lower lifecycle costs, reduce downtime during upgrades, and improve uptime for critical control panels in manufacturing or process facilities.
