Eaton PXM1000TB11-1 Power Xpert Meter 1000 - CE/UL
Part Number: PXM1000TB11-1
Quick Summary
Power Xpert meter 1000 is a compact power and energy meter for panel and utility applications. Engineers often need reliable metering that doesn’t disrupt existing wiring or add complexity to the control system. This device carries CE marking and UL Recognized certification, ensuring compliance across global electrical standards. Built-in RS485 with Modbus-RTU and DNP3.0 enables straightforward integration with SCADA, BMS, and PLC networks, reducing engineering effort and project risk. For businesses, this translates to faster deployment, improved energy visibility, and lower total cost of ownership through streamlined procurement and maintenance.
Product Information
Extended Description
PXM1000TB11-1 Eaton: PXM 1000 power and energy meter, Ring terminal, Din-rail mount transducer without display,, Frequency range 45-65Hz, Nominal current input 1A, Power supply 100-415Vac or 100-300Vdc, Built-in RS485 port with Modbus-RTU and DNP3.0 protocol
Product Name
Eaton Power Xpert meter 1000
Catalog Number
PXM1000TB11-1
UPC
786689771942
Product Length/Depth
4 in
Product Height
4 in
Product Width
2.5 in
Product Weight
1 lb
Compliances
Contact Manufacturer CE Marked
Certifications
UL Recognized
Power Systems Experience Center Tour – Metering Focus
Power Systems Experience Center Tour – Metering Focus
Power Xpert Meter 1000 meter software version 3.7.3
Eaton Specification Sheet - PXM1000TB11-1
Feature: DIN-rail mountable, ring terminal, and compact 4x4 inch footprint. Business Impact: Maximizes panel space while simplifying retrofits and replacements in crowded cabinets. Application: Industrial control panels, machine enclosures, and switchgear assemblies where space is at a premium. Feature: Nominal current input of 1A. Business Impact: Enables low-current metering for low-power loads and metering circuits without oversized transducers. Application: Low-power motors, instrumentation panels, and energy monitoring retrofits. Feature: Power supply range 100-415Vac or 100-300Vdc. Business Impact: Flexible installation across AC and DC systems reduces wiring variety and stock requirements. Application: Mixed-voltage facilities and transition projects in manufacturing and process industries. Feature: Built-in RS485 port with Modbus-RTU and DNP3.0. Business Impact: Seamless integration into existing SCADA/BMS without external gateways, improving data accuracy and uptime. Application: Energy management dashboards, remote monitoring, and predictive maintenance workflows. Feature: Frequency range 45-65Hz. Business Impact: Suitable for global power environments and grid-tollowed variations, ensuring accurate energy measurement. Application: Utilities, data centers, and automated production lines. Feature: Certifications include CE Marked and UL Recognized. Business Impact: Reduces compliance risk and accelerates procurement cycles with confidence in standard conformity. Application: Global deployments in regulated industries such as food & beverage, pharmaceuticals, and OEM equipment. Feature: Communication protocols for interoperability. Business Impact: Eliminates integration bottlenecks by supporting Modbus-RTU and DNP3.0 out of the box. Application: PLC/SCADA integration in plant networks and energy-automation ecosystems. Feature: Without a dedicated display, rely on external monitors and software. Business Impact: Lower hardware cost and easier enclosure design while preserving data access through software interfaces. Application: Remote commissioning, data logging, and energy analytics platforms. Industry-specific context: As plants pursue energy transparency and regulatory reporting, this meter’s combination of compact form factor, flexible power supply, 1A input, and standard comms provides a pragmatic path to faster deployment, reduced wiring complexity, and measurable efficiency gains across multiple lines and cells.
Get a Quick Quote for a Eaton PXM1000TB11-1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton PXM1000TB11-1?
Enquire Now
FAQs
The PXM1000TB11-1 is designed for DIN-rail mounting with a ring terminal connection option, delivering a compact 4x4 inch footprint. Compatibility is ensured with standard low-voltage panels and typical control cabinets. When retrofitting, verify space in the enclosure, route RS485 wiring to your PLC/SCADA network, and ensure mounting is secure to avoid vibration-induced contact resistance. The device’s display-less design means you’ll rely on external software for visualization, so plan your monitoring architecture accordingly.
Key specs include nominal current input of 1A and a flexible power supply range of 100-415Vac or 100-300Vdc, with a frequency range of 45-65Hz. The built-in RS485 port supports Modbus-RTU and DNP3.0, enabling seamless integration with most SCADA and energy management systems. These characteristics minimize additional hardware, reduce wiring complexity, and improve data accuracy for energy audits and demand reporting.
Yes. Its DIN-rail mounting, compact footprint, and rugged certifications (CE Marked and UL Recognized) make it suitable for demanding environments. The 1A input keeps wiring simple for panel-level metering, while Modbus-RTU and DNP3.0 compatibility supports robust monitoring in automated production lines and energy management initiatives.
The meter carries CE marking and UL Recognized certification, signaling compliance with European and North American electrical safety and performance standards. These certifications help meet regulatory requirements, facilitate vendor approvals, and reduce procurement risk in regulated industries and global deployments.
By providing accurate energy data via standard communication protocols, the meter enables precise cost allocation, energy optimization, and fault detection. Its compact form factor reduces panel space and installation time, while flexible power input and external visualization options lower hardware and maintenance costs. The combination shortens project timelines and supports faster regulatory reporting and continuous improvement initiatives.
