Eaton PXM1000TB13 Power Xpert Meter 1000 - UL Recognized
Part Number: PXM1000TB13
Quick Summary
The Eaton Power Xpert meter 1000 delivers precise power and energy monitoring for electrical distribution panels. Engineers often struggle with incomplete visibility, mismatched data protocols, and costly engineering time when integrating meters into control systems. This device carries CE Marked compliance and UL Recognized certification, with built-in RS485 supporting Modbus-RTU and DNP3.0 for seamless SCADA connectivity. In practice, it accelerates commissioning, improves energy accounting accuracy, and scales with facility expansions while staying compliant with industry standards. Manufacturers and installers will appreciate the compact DIN-rail form, the absence of a local display for unobtrusive paneling, and ready software support through Power Xpert Meter software.
Product Information
Extended Description
PXM1000TB13 Eaton: PXM 1000 multifunction power and energy meter, Din-rail mount transducer without display,, Frequency range 45-65Hz, Nominal current input 333mV, Power supply 100-415Vac or 100-300Vdc, Built-in RS485 port with Modbus-RTU and DNP3.0 protocol
Product Name
Eaton Power Xpert meter 1000
Catalog Number
PXM1000TB13
UPC
786689771959
Product Length/Depth
4 in
Product Height
4 in
Product Width
2.5 in
Product Weight
1 lb
Compliances
Contact Manufacturer CE Marked
Certifications
UL Recognized
Power Xpert Meters
Power Xpert Meters
Power Xpert Meter 1000 meter software version 3.7.3
Eaton Specification Sheet - PXM1000TB13
Feature: DIN-rail mounting with no display keeps installation compact and panel-friendly. Impact: reduces space, simplifies wiring, lowers enclosure costs. Application: ideal for retrofit projects and new panel builds in manufacturing lines. Feature: Universal power supply 100-415 Vac or 100-300 Vdc and a 45-65 Hz range. Impact: supports diverse plant voltages, enabling single-supply installations and fewer part numbers. Application: suitable for mixed-voltage environments in data centers and OEM machinery. Feature: 333 mV nominal current input. Impact: enables accurate measurements across varied loads, improving energy accounting and billable consumption. Application: electrical distribution metering in industrial panels. Feature: Built-in RS485 port with Modbus-RTU and DNP3.0. Impact: seamless integration with SCADA and EMS, reducing commissioning time and risk. Application: connects to Power Xpert software or third-party systems for centralized monitoring. Feature: Certifications: CE Marked and UL Recognized. Impact: ensures regulatory compliance and procurement confidence in global deployments. Application: manufacturing floors, data centers, and process facilities with strict auditing. Feature: Compact dimensions and light weight (4 in x 4 in x 2.5 in; 1 lb). Impact: easy replacement and retrofit in tight spaces without structural changes. Application: panel retrofits and new builds needing space-efficient energy monitoring.
Get a Quick Quote for a Eaton PXM1000TB13
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton PXM1000TB13?
Enquire Now
FAQs
The PXM1000TB13 is a DIN-rail mounted multifunction power and energy meter without a display. It accepts a 100–415 Vac or 100–300 Vdc supply and a 45–65 Hz frequency range, with a nominal 333 mV input. It includes a built-in RS485 port for Modbus-RTU and DNP3.0, enabling quick, panel-wide integration into existing control systems.
The meter provides a built-in RS485 interface supporting Modbus-RTU and DNP3.0. This enables seamless communication with SCADA and energy management systems, including Eaton’s Power Xpert software ecosystem, reducing integration time and ensuring consistent data flow for reporting and analysis.
Yes. The PXM1000TB13 is CE Marked and UL Recognized, addressing essential safety and compliance requirements for industrial environments. This reduces procurement risk and supports regulatory audits across global facilities.
Key inputs include a nominal 333 mV current input and a wide supply range of 100–415 Vac or 100–300 Vdc. The device operates at 45–65 Hz, making it compatible with mixed-voltage panels and diverse machinery, while retaining accurate energy and power monitoring across profiles.
The PXM1000TB13 improves energy visibility and accuracy, enabling precise billing and cost reduction. Its open RS485 interfaces allow easy integration with EMS/SCADA, supporting proactive energy optimization, faster commissioning, and scalable monitoring as facilities expand.
