Eaton PXM1000TB15 Power Xpert meter 1000 - UL Recognized
Part Number: PXM1000TB15
Quick Summary
Power Xpert meter 1000 by Eaton is a DIN-rail energy and power meter for industrial control panels. Engineers often struggle with meters that are bulky or don’t support both AC and DC inputs or DIN-rail mounting. UL Recognized and CE Marked certifications provide regulatory confidence while the unit operates across a 45–65 Hz range, ensuring compatibility with diverse power systems. This compact, display-free transducer integrates with Eaton software to deliver robust energy analytics, enabling scalable energy management across facilities and reducing total cost of ownership.
Product Information
Extended Description
PXM1000TB15 Eaton: Eaton Power Xpert meter 1000, multifunction power and energy meter, Din-rail mount transducer without display,, Frequency range 45-65Hz, Nominal current input 5A, Power supply 100-415Vac or 100-300Vdc
Product Name
Eaton Power Xpert meter 1000
Catalog Number
PXM1000TB15
UPC
786689772017
Product Length/Depth
4 in
Product Height
4 in
Product Width
2.5 in
Product Weight
0.883 lb
Compliances
Contact Manufacturer CE Marked
Certifications
UL Recognized
Power Systems Experience Center Tour – Metering Focus
Power Systems Experience Center Tour – Metering Focus
Power Xpert Meter 1000 meter software version 3.7.3
Eaton Specification Sheet - PXM1000TB15
Feature: DIN-rail mounted multifunction energy meter. Benefit: Simplifies panel integration and reduces installation time, enabling faster deployment in manufacturing lines and data centers. Application: Ideal for control panels and motor control centers where space is at a premium and quick commissioning is required. Feature: Nominal current input 5A. Benefit: Accurate metering with standard current input supports precise energy monitoring without custom wiring. Application: Used for load profiling on configurable industrial circuits and energy audits. Feature: Flexible power supply 100-415Vac or 100-300Vdc. Benefit: Versatile powering options reduce wiring complexity and expand compatibility with mixed DC and AC infrastructure. Application: Suitable for mixed-energy environments in plant automation. Feature: Frequency range 45–65 Hz. Benefit: Maintains measurement integrity across most regional grids, reducing calibration overhead. Application: Data centers and manufacturing facilities operating outside 50/60 Hz norms. Feature: Compact dimensions 4 in x 4 in x 2.5 in and weight under 1 lb. Benefit: Minimal panel footprint and ease of replacement in crowded panels. Application: Retrofit projects and space-constrained switchgear installations. Feature: DIN-rail transducer without display. Benefit: Lower cost and simpler integration with external displays or software dashboards. Application: Systems that rely on centralized HMI for energy analytics. Feature: Software compatibility with Power Xpert Meter 1000 suite (v3.x). Benefit: Streamlined configuration, commissioning, and long-term maintenance. Application: Enterprise-level energy monitoring and performance reporting across sites.
