Eaton Power Xpert meter 1000 PXM1000TB43-1 - UL Recognized
Part Number: PXM1000TB43-1
Quick Summary
Power Xpert meter 1000 is Eaton's compact power and energy meter for industrial control panels. Integrations with existing wiring can be complex, often delaying energy data collection and reporting. UL Recognized and CE Marked certifications support global deployment, while 45–65 Hz operation suits mixed power systems. As a DIN-rail mounted transducer with RS485, Modbus-RTU and DNP3.0, it enables scalable monitoring and faster energy insights for procurement and maintenance teams. Its compact footprint and simple DIN-rail installation save panel space and time. This translates into improved asset reliability, energy accounting accuracy, and traceable compliance data for audits. Get measurable ROI through better load management and reduced metering errors.
Product Information
Extended Description
PXM1000TB43-1 Eaton: PXM 1000 power and energy meter, Ring terminal, Din-rail mount transducer without display,, Frequency range 45-65Hz, Nominal current input 333mV, Power supply 20-60Vdc, Built-in RS485 port with Modbus-RTU and DNP3.0 protocol
Product Name
Eaton Power Xpert meter 1000
Catalog Number
PXM1000TB43-1
UPC
786689770983
Product Length/Depth
4 in
Product Height
4 in
Product Width
2.5 in
Product Weight
1 lb
Compliances
Contact Manufacturer CE Marked
Certifications
UL Recognized
Power Systems Experience Center Tour – Metering Focus
Power Systems Experience Center Tour – Metering Focus
Power Xpert Meter 1000 meter software version 3.7.3
Eaton Specification Sheet - PXM1000TB43-1
Feature: RS485 port with Modbus-RTU and DNP3.0 protocols → Business Impact: Enables seamless integration with existing SCADA, PMIs, and energy management systems, reducing custom wiring and integration costs. Application: Ideal for plant-wide energy data collection and remote monitoring without deploying new communication infrastructure. Feature: DIN-rail mount transducer, ring terminal, no display → Business Impact: Space-efficient, quick retrofits in crowded control cabinets, enabling faster project timelines. Application: Retrofit projects and new panel installations where displayless meters simplify wiring and labeling. Feature: Frequency range 45–65 Hz → Business Impact: Compatibility with both North American and international electrical systems, reducing redesigns and stocking of multiple meter types. Application: Mixed-grid facilities and multi-site deployments. Feature: Power supply 20–60 Vdc → Business Impact: Flexible powering from common control voltages, lowering wiring complexity and energy losses. Application: Remote panels and installations with limited AC supply access. Feature: Nominal current input 333 mV → Business Impact: Low burden measurement improves accuracy and reduces sensor wiring requirements. Application: High-precision energy profiling for load shedding and efficiency projects. Feature: Certifications UL Recognized and CE Marked → Business Impact: Compliance-ready for global markets, simplifying procurement and audit processes. Application: Regulatory-driven deployments in manufacturing and data centers, with rapid supplier qualification. Feature: Compact dimensions (4 in x 4 in x 2.5 in) and 1 lb weight → Business Impact: Minimal physical footprint, easier cabinet planning, and reduced shipping costs. Application: New installations in space-constrained panels and retrofits where weight matters.
Get a Quick Quote for a Eaton PXM1000TB43-1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton PXM1000TB43-1?
Enquire Now
FAQs
The PXM1000TB43-1 is designed as a DIN-rail mounted, display-free transducer with a ring terminal; it fits standard control panels and adds energy metering without significant rewiring. Compatible with RS485 networks supporting Modbus-RTU and DNP3.0, it integrates into existing SCADA or energy management setups with minimal disruption.
It includes built-in RS485 communication with Modbus-RTU and DNP3.0 protocols. Integration with SCADA systems is straightforward using these standard interfaces; you can pull energy, demand, and power quality data into your HMI, historian, or energy analytics platform without custom drivers.
Yes. The meter operates over a broad frequency range of 45–65 Hz, making it suitable for both 50 Hz and 60 Hz electrical environments. Its dual certifications (UL Recognized and CE Marked) support compliance for global deployments across manufacturing facilities and data centers.
The PXM1000TB43-1 carries UL Recognized certification and CE Marking, which validate safety and conformity for U.S., Canada, and European markets. These certifications simplify supplier qualification, procurement, and audit readiness in regulated industries.
By delivering accurate real-time energy data with standard communication, it reduces wiring complexity, minimizes installation time, and improves load management insights. This leads to lower energy waste, better maintenance planning, and faster anomaly detection, contributing to a favorable return on investment over typical facility lifecycles.
