Eaton PXM1000TB45 Power Xpert Meter - UL Recognized
Part Number: PXM1000TB45
Quick Summary
Power Xpert meter 1000 from Eaton monitors electrical power in industrial panels. Many users struggle to obtain accurate, timely energy data when meters sit behind displays or lack integration options. It carries CE Marked European compliance and UL Recognized safety certification, signaling reliability in harsh environments. Installing it on a DIN-rail and accessing data over RS485 enables straightforward integration with Modbus-RTU and DNP3.0-capable systems, reducing project risk. This meter delivers essential energy visibility for industrial IoT, enabling 1-2% efficiency gains and better asset utilization through remote monitoring and scalable deployment.
Product Information
Extended Description
PXM1000TB45 Eaton: PXM 1000 multifunction power and energy meter, Din-rail mount transducer without display,, Frequency range 45-65Hz, Nominal current input 5A, Power supply 20-60Vdc, Built-in RS485 port with Modbus-RTU and DNP3.0 protocol
Product Name
Eaton Power Xpert meter 1000
Catalog Number
PXM1000TB45
UPC
786689771034
Product Length/Depth
4 in
Product Height
4 in
Product Width
2.5 in
Product Weight
1 lb
Compliances
Contact Manufacturer CE Marked
Certifications
UL Recognized
Power Xpert Meters
Power Xpert Meters
Power Xpert Meter 1000 meter software version 3.7.3
Eaton Specification Sheet - PXM1000TB45
Feature: DIN-rail mounted, with a compact 4x4 in footprint and no built-in display. Benefit: Saves panel space and reduces wiring complexity while keeping the meter accessible for remote reading through communication protocols. Application: Ideal for panel boards in manufacturing, packaging lines, and machine centers where space is at a premium. Feature: Nominal current input of 5A. Benefit: Simplifies installation by reducing the need for external current transformers, lowering upfront costs and leakage paths. Application: DC and AC distribution points in control panels requiring compact metering solutions. Feature: Wide power-supply range 20–60Vdc. Benefit: Flexible, low-power operation compatible with modern control cabinets and embedded systems, improving reliability. Application: Modern industrial automation racks and energy management deployments. Feature: 45–65 Hz frequency range. Benefit: Supports diverse grid environments and international installations without additional hardware changes. Application: Global manufacturing facilities with variable utility frequency. Feature: RS485 port with Modbus-RTU and DNP3.0. Benefit: Smooth SCADA/EMS integration, rapid commissioning, and scalable data collection. Application: Energy monitoring across multiple substations and line monitoring in industrial plants. Feature: Certifications – CE Marked and UL Recognized. Benefit: Ensures regulatory compliance and safety, reducing risk in regulated environments. Application: Use in European and North American facilities requiring formal approvals. Feature: Software availability (Power Xpert Meter software v3.7.3). Benefit: Up-to-date features, improved diagnostics, and easier firmware management. Application: Commissioning and ongoing maintenance of power/energy management systems.
