Eaton PXM1000TB4R Power Xpert Meter 1000 - UL Recognized
Part Number: PXM1000TB4R
Quick Summary
Power Xpert meter 1000 is a DIN-rail energy and power meter for panel-level monitoring. Engineers often struggle with wiring complexity and disparate data sources in compact switchgear. It carries CE Marked compliance and UL Recognized certification, delivering regulatory assurance for safety and reliability. This solution integrates seamlessly with RS485 networks and PXM 1000 Rogowski Coil CTs, enabling efficient energy management and advanced monitoring across industrial installations.
Product Information
Extended Description
PXM1000TB4R Eaton: PXM 1000 multifunction power and energy meter Din-rail mount transducer without display Frequency: 45-65 Hz, Works exclusively with PXM 1000 Rogowski Coil CTs Power supply 20-60Vdc Built-in RS485 port with Modbus-RTU and DNP3.0 protocol
Product Name
Eaton Power Xpert meter 1000
Catalog Number
PXM1000TB4R
UPC
786689771058
Product Length/Depth
4 in
Product Height
4 in
Product Width
2.5 in
Product Weight
1 lb
Compliances
Contact Manufacturer CE Marked
Certifications
UL Recognized
Power Systems Experience Center Tour – Metering Focus
Power Systems Experience Center Tour – Metering Focus
Power Xpert Meter 1000 meter software version 3.7.3
Eaton Specification Sheet - PXM1000TB4R
Feature: DIN-rail mounted transducer without a local display. Benefit: minimizes panel clutter and enables clean integration with external HMIs or SCADA. Application: motor control centers and compact switchgear where centralized display is unnecessary. Feature: Frequency range of 45–65 Hz. Benefit: ensures compatibility with diverse power systems and variable frequency drives, reducing integration risk. Application: AC plants and manufacturing lines with mixed frequencies. Feature: Power supply 20–60 Vdc. Benefit: flexible power options for retrofits and new installs without separate power provisions. Application: control panels and DC-powered enclosures. Feature: Built-in RS485 port with Modbus-RTU and DNP3.0. Benefit: straightforward senior- or plant-wide data access and integration into EMS/SCADA. Application: energy management systems and remote monitoring. Feature: Exclusive compatibility with PXM 1000 Rogowski Coil CTs. Benefit: safe, high-accuracy non-contact current sensing in confined spaces. Application: high-current MCCs and panelized power feeds. Feature: Compact dimensions (4 x 4 x 2.5 in) and 1 lb weight. Benefit: easy DIN-rail installation with minimal footprint. Application: space-constrained panel boards and retrofit projects. Feature: CE Marked and UL Recognized. Benefit: regulatory compliance and reliability assurances for aerospace, manufacturing, and process facilities. Application: procurement and compliance workflows.
Get a Quick Quote for a Eaton PXM1000TB4R
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton PXM1000TB4R?
Enquire Now
FAQs
The PXM1000TB4R is designed as a DIN-rail mounted transducer without a local display. Install it directly on the DIN rail inside the panel and connect the Rogowski Coil CTs for current sensing. Provide 20–60 Vdc power and use the built-in RS485 port for Modbus-RTU or DNP3.0 communications to your SCADA or EMS.
The meter includes a built-in RS485 port that supports Modbus-RTU and DNP3.0 protocols. Configure the device address and parity as per your network architecture and wire RS485 daisy-chain connections to your SCADA or energy management system for centralized data access.
Yes. The device is CE Marked and UL Recognized, providing regulatory compliance and safety assurance across many industrial environments. This reduces procurement risk and simplifies audit processes when deploying metering in process or manufacturing facilities.
The meter measures 4 inches in length and height, with a 2.5 inch width, and weighs 1 pound. Its compact footprint supports easy installation in restricted panel spaces and alongside other DIN-rail equipment.
Yes. The PXM1000TB4R is designed to work exclusively with PXM 1000 Rogowski Coil CTs, enabling accurate, non-contact current sensing in tight spaces and eliminating the need for bulky current transformers in many installations.
