Eaton PXM1000TB4R-1 Power Xpert Meter 1000 - UL Recognized
Part Number: PXM1000TB4R-1
Quick Summary
The Eaton Power Xpert Meter 1000 provides precise power and energy measurement for industrial power management. A common pain point is turning raw data into actionable insights across sites with different frequencies and protocols. This meter carries CE marking and UL Recognized certification, underscoring safety, reliability, and regulatory readiness. Designed for seamless DIN-rail installation with ring-terminal CT connections, it communicates via built-in RS485 using Modbus-RTU and DNP3.0. With 45–65 Hz compatibility and a 20–60 Vdc power supply, it enables scalable, compliant energy monitoring across facilities.
Product Information
Extended Description
PXM1000TB4R-1 Eaton: PXM 1000 power and energy meter, Ring Terminal, Din-rail mount transducer without display Frequency: 45-65 Hz, Works exclusively with PXM 1000 Rogowski Coil CTs Power supply 20-60Vdc Built-in RS485 port with Modbus-RTU and DNP3.0 protocol
Product Name
Eaton Power Xpert meter 1000
Catalog Number
PXM1000TB4R-1
UPC
786689771065
Product Length/Depth
4 in
Product Height
4 in
Product Width
2.5 in
Product Weight
1 lb
Compliances
Contact Manufacturer CE Marked
Certifications
UL Recognized
Power Systems Experience Center Tour – Metering Focus
Power Systems Experience Center Tour – Metering Focus
Power Xpert Meter 1000 meter software version 3.7.3
Eaton Specification Sheet - PXM1000TB4R-1
Compact, DIN-rail mounted meter with ring-terminal transducer → Space-saving and quick installation reduces panel wiring time and commissioning costs. This translates to faster project deployment and lower total cost of ownership on new builds or retrofit projects. Compatible with PXM1000 Rogowski Coil CTs, it enables flexible current sensing for large loads while maintaining safe, accurate measurements across motor drives and distribution panels. Data can be integrated into SCADA or energy management systems via RS485 Modbus-RTU and DNP3.0 → Improves visibility, accelerates issue detection, and supports compliance reporting for audits and energy optimization projects. Frequency range of 45–65 Hz supports multi-country deployments → Enables global operations and reduces the need for multiple metering instruments in diversified electrical networks. The 20–60 Vdc power supply ensures reliable operation from standard control circuits, minimizing wiring requirements and improving resilience in harsh manufacturing environments. Its compact 4 in by 4 in by 2.5 in form factor (1 lb) allows easy retrofits in crowded panels → Saves space, reduces hardware footprint, and simplifies future upgrades. Built-in RS485 port with Modbus-RTU and DNP3.0 provides straightforward integration with modern automation architectures → Lowers integration risk and shortens commissioning times in utilities and industrial facilities.
