Eaton PXM1K-DINADPT Power Xpert Mounting Adapter - DIN
Part Number: PXM1K-DINADPT
Quick Summary
PXM1K-DINADPT Power Xpert meter 1000 mounting adapter enables reliable DIN-rail installation for Eaton's metering solution across industrial panels. In tight spaces, engineers struggle with alignment and service access; this adapter simplifies mounting, reduces wiring congestion, and speeds commissioning. Certification details such as SIL, CE, and IP ratings are not listed in the provided data; verify exact ratings in Eaton’s official datasheet to ensure regional compliance. In practice, the adapter’s compact footprint—2.4 in long, 0.6 in high, 3.5 in wide—and light 0.1 lb weight support scalable deployments, enabling quick swaps and easy multi-meter configurations in distributed energy setups. By consolidating mounting and alignment into a single component, facilities can standardize panel configurations and reduce the time-to-field.
Product Information
Extended Description
PXM1K-DINADPT Eaton: Eaton Power Xpert Meter 1000 DIN Rail mounting adapter
Product Name
Eaton Power Xpert meter 1000 mounting adapter
Catalog Number
PXM1K-DINADPT
UPC
786689364168
Product Length/Depth
2.4 in
Product Height
0.6 in
Product Width
3.5 in
Product Weight
0.1 lb
Type
Mounting Adapter
Power Systems Experience Center Tour – Metering Focus
Power Systems Experience Center Tour – Metering Focus
Power Xpert Meter 1000 meter software version 3.7.3
Eaton Specification Sheet - PXM1K-DINADPT
Feature: Compact DIN-rail mounting design aligns the Eaton Power Xpert Meter 1000 securely on standard rails. Benefit: Improves vibration resistance and wiring organization, translating to more reliable data capture in busy panels. Application: Ideal for crowded switchgear enclosures and energy-management panels where space is at a premium. Feature: Precise, lightweight footprint—2.4 in length, 0.6 in height, 3.5 in width, 0.1 lb weight. Benefit: Enables tight installations without compromising service access or future upgrades. Application: Suitable for multi-meter deployments in compact industrial cabinets and distributed energy setups. Feature: Dedicated compatibility with Power Xpert Meter 1000 family. Benefit: Simplifies procurement and installation, reducing time-to-first-read and supporting repeatable installs across sites. Application: Field retrofits and new builds requiring consistent meter alignment and connector compatibility. Feature: Type Mounting Adapter with DIN-rail compatibility. Benefit: Minimizes misalignment risk during installation and enables quick swaps or upgrades without disassembling the panel. Application: Industrial panels and maintenance-friendly installations in utility and manufacturing environments. Feature: Availability of supporting documentation and software. Benefit: Streamlines commissioning and compliance checks, ensuring engineers have access to datasheets and upgrade assets. Application: Energy-management projects and panel upgrades requiring traceable technical references.
Get a Quick Quote for a Eaton PXM1K-DINADPT
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton PXM1K-DINADPT?
Enquire Now
FAQs
The PXM1K-DINADPT is engineered as the mounting adapter for the Power Xpert Meter 1000 and is designed for standard 35 mm DIN rails found in most industrial panels. It ensures precise alignment with the meter’s connectors, reducing misalignment risk during installation and enabling quicker field mounting and subsequent maintenance.
The adapter footprint is 2.4 inches in length, 3.5 inches in width, and 0.6 inches in height, with a weight of 0.1 pounds. These compact dimensions allow installation in tight spaces while preserving access for wiring and future servicing.
Yes. The mounting adapter is explicitly designed for DIN-rail installations to support Eaton Power Xpert Meter 1000 deployments in electrical panels and energy-management systems, enabling standardized mounting, quick upgrades, and scalable multi-meter configurations.
Certification details such as SIL, CE, and IP ratings are not specified in the provided data. To confirm compliance, consult the official Eaton datasheet for PXM1K-DINADPT and verify regional certification requirements with your procurement or compliance team.
By enabling secure, plug-in mounting and consistent alignment, the adapter reduces installation time, minimizes commissioning risk, and simplifies future maintenance or upgrades. These factors collectively lower labor costs and downtime in panel upgrades and energy-management deployments.
