Eaton PXM350MA6521-2A1S1 Enclosed Meter - CE Marked
Part Number: PXM350MA6521-2A1S1
Quick Summary
Eaton enclosed meter is a precise energy measurement device for panel boards and industrial facilities. Professionals often face challenges integrating meters into existing Eaton PXG environments while meeting stringent accuracy and regulatory requirements. This model delivers ANSI/IEEE Std C12.20 (0.2% accuracy), IEC 687 (0.2% accuracy), and CE Marking, providing reliable performance in harsh industrial settings. Designed for power management applications, it supports a 120-240 VAC power supply and RS485 communication wired to PXG COM 1, simplifying installation and ensuring consistent data across the system. By aligning with Eaton's PXM/PXG ecosystem, it reduces wiring complexity, accelerates deployment, and supports scalable energy monitoring programs.
Product Information
Extended Description
PXM350MA6521-2A1S1 Eaton: Eaton Enclosed meter, 11-PXM350(MA6321),PXG900,NEMA 12(120/240V,No CPT) with Window Kit,Vdc Power Supply:PXG,All PXM RS485 Wired to PXG COM 1,1-3PH/4W Main Fuse Disconnct,Control Power Fuse Disconect:per PXM & PXG,CT Terminal Block per PXM
Product Name
Eaton enclosed meter
Catalog Number
PXM350MA6521-2A1S1
UPC
786689649555
Product Length/Depth
24 in
Product Height
10 in
Product Width
24 in
Product Weight
100 lb
Compliances
CE Marked
Certifications
ANSI/IEEE Std C12.20 (0.2% accuracy) ANSI/IEEE Std C62.41 IEC 687 (0.2% accuracy)
Power supply
120-240VAC
Enclosure
NEMA 12
Metering devices, protective relays, software and connectivity
Metering devices, protective relays, software and connectivity
Eaton's Enclosed Meters
Eaton Specification Sheet - PXM350MA6521-2A1S1
Rugged NEMA 12 enclosure protects sensitive meters from dust, moisture, and impact in harsh environments, reducing downtime and preserving measurement accuracy in production halls and electrical rooms. This containment translates to lower maintenance costs and longer interval reliability for panel boards and critical facilities. The 120-240 VAC power supply offers broad compatibility with standard plant power, simplifying electrical design and minimizing transformer requirements across diverse industrial sites. RS485 wired to PXG COM 1 enables seamless data sharing with Eaton's PXG power management system, cutting commissioning time and reducing wiring errors in energy-management projects. A window kit facilitates quick visual verification of meters without opening enclosures, while CT terminals, main fuse disconnects, and control power fuse disconnects per PXM enhance safety and serviceability. With dimensions of 24 in L × 24 in W × 10 in H and a 100 lb weight, the unit is built for durability in demanding environments and supports scalable deployments across facilities and data centers.
Get a Quick Quote for a Eaton PXM350MA6521-2A1S1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton PXM350MA6521-2A1S1?
Enquire Now
FAQs
Start with securing the NEMA 12 enclosure in a suitable electrical room or panel area. Mount the device using standard hardware, connect the 120-240 VAC power supply to the designated input, and wire RS485 to PXG COM 1. Attach CT terminals per PXM and install the window kit for quick visual checks. Ensure main fuse disconnect and control power fuse disconnect are properly configured per PXM and PXG guidelines. Verify connections, test continuity, and confirm communication with PXG for accurate data readouts before commissioning.
The PXM350MA6521-2A1S1 operates on a 120-240 VAC power supply and is housed in a NEMA 12 enclosure. It weighs about 100 lb and measures 24 in L × 24 in W × 10 in H. It features RS485 communication wired to PXG COM 1 and supports robust energy measurement with ANSI/IEEE C12.20 (0.2% accuracy) and IEC 687 (0.2% accuracy) certifications, ensuring high-precision monitoring in industrial environments.
Yes. The enclosure is rated NEMA 12 and CE Marked, with high-precision ANSI/IEEE C12.20 and IEC 687 certifications, making it appropriate for data centers, manufacturing floors, and commercial facilities. Its RS485 integration to PXG streamlines data collection for energy dashboards, demand management, and compliance reporting, while the rugged design withstands challenging environments typical of industrial automation deployments.
This Eaton enclosed meter carries CE Marking and certifications including ANSI/IEEE Std C12.20 with 0.2% accuracy and IEC 687 with 0.2% accuracy. These standards ensure measurement reliability, electrical safety, and compliance with common regulatory requirements in both North American and international markets, supporting audit-ready energy data for facilities, industry, and infrastructure projects.
The enclosure and robust build reduce dust ingress and wear, minimizing maintenance downtime. Integration with PXG reduces wiring and commissioning time, speeding up project delivery and data availability for energy management, which translates to improved efficiency, lower energy waste, and faster ROI on monitoring investments. The 120-240 VAC compatibility and window kit further streamline installation and ongoing visibility.
