Eaton PXM350MA6541-3A1A Enclosed Meter - CE Marked
Part Number: PXM350MA6541-3A1A
Quick Summary
Enclosed meter delivers precise energy measurement for industrial power distribution in heavy manufacturing facilities. Many engineers grapple with unreliable metering, limited control-system integration, and audit-driven compliance. This model carries CE Marked compliance and ANSI/IEEE C12.20 (0.2% accuracy) plus IEC 687 (0.2% accuracy) certifications, providing accuracy and safety in demanding environments. With a rugged NEMA 3R enclosure, it is suitable for indoor and protected outdoor spaces, and it supports 120–240VAC operation, 1–3 phase/4-wire configurations, and RS485 wired to PXG COM 1 for straightforward integration. Window kit and PXG power-supply compatibility further simplify installation and maintenance, enabling faster energy visibility, accurate billing, and improved energy-management decisions across facilities.
Product Information
Extended Description
PXM350MA6541-3A1A Eaton: Eaton Enclosed meter, 11-PXM350(MA6321),PXG900,NEMA 12(120/240V,No CPT) with Window Kit,Vdc Power Supply:PXG,All PXM RS485 Wired to PXG COM 1,1-3PH/4W Main Fuse Disconnct,Control Power Fuse Disconnct:per PXM & PXG,CT Terminal Block per PXM
Product Name
Eaton enclosed meter
Catalog Number
PXM350MA6541-3A1A
UPC
786689649562
Product Length/Depth
16 in
Product Height
8 in
Product Width
24 in
Product Weight
100 lb
Compliances
CE Marked
Certifications
ANSI/IEEE Std C12.20 (0.2% accuracy) ANSI/IEEE Std C62.41 IEC 687 (0.2% accuracy)
Power supply
120-240VAC
Enclosure
NEMA 3R
Metering devices, protective relays, software and connectivity
Metering devices, protective relays, software and connectivity
Eaton's Enclosed Meters
Eaton Specification Sheet - PXM350MA6541-3A1A
Rugged NEMA 3R enclosure protects sensitive metering electronics from dust, moisture, and incidental contact, reducing field failures and maintenance costs while allowing flexible siting in both indoor and protected outdoor spaces. The 120–240VAC power input streamlines procurement and deployment across mixed facilities, lowering spare parts inventory and enabling a single meter footprint for multiple assets. High-accuracy metering with ANSI/IEEE C12.20 (0.2%) and IEC 687 (0.2%) certifications delivers trustworthy data for billing, energy dashboards, and regulatory compliance, reducing audit risk. RS485 connectivity to PXG COM 1 and full PXM integration minimize wiring errors and shorten commissioning times, while the window kit and PXG-compatible power supply support rapid installation and long-term reliability. Overall, the design supports efficient energy management programs, data-driven maintenance, and scalable deployment across industrial sites.
Get a Quick Quote for a Eaton PXM350MA6541-3A1A
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton PXM350MA6541-3A1A?
Enquire Now
FAQs
Installation starts with mounting the NEMA 3R enclosure in a suitable panel or wall location. Wire the meter’s RS485 interface to PXG COM 1 and connect the 120-240VAC power supply. Utilize the CT terminal block for phase measurement and, if needed, add the Window Kit for easy visual verification. The process minimizes wiring errors and accelerates commissioning.
The PXM350MA6541-3A1A delivers 0.2% accuracy per ANSI/IEEE Std C12.20 (and IEC 687), ensuring reliable energy data for billing and reporting. It supports 1–3 phase and 4-wire configurations, with a 120–240VAC power input, making it suitable for a wide range of industrial power distribution setups.
Yes. The unit is built with a rugged NEMA 3R enclosure designed for indoor and protected outdoor spaces. This protection helps safeguard sensitive metering electronics from dust, moisture, and incidental contact, reducing field maintenance and extending the service life in challenging environments.
Key specs include a 120-240VAC power supply, NEMA 3R enclosure, 16 in length, 24 in width, 8 in height, and an approximate weight of 100 lb. The meter accommodates 11-PXM MA segments and PXG integration, with RS485 connectivity and a window kit option to simplify installation and verification.
The meter delivers precise energy data for dashboards, audits, and billing, enabling accurate consumption tracking, anomaly detection, and cost allocation. Its PXG-ready RS485 integration reduces deployment time, while robust certifications and protections support regulatory compliance and long-term operational efficiency across facilities.
