Eaton PXMP-MB-2C-D Enclosed Meter - NEMA12 (600V)
Part Number: PXMP-MB-2C-D
Quick Summary
The Eaton enclosed meter PXMP-MB-2C-D provides compact, accurate three-phase metering for industrial panels. Engineers and procurement teams often struggle with reliable, space-efficient meters that fit standard NEMA 12 enclosures while delivering quick commissioning. This model carries ANSI/IEEE Std C12.20 (0.2% accuracy), ANSI/IEEE Std C62.41, and IEC 687 (0.2% accuracy) certifications, plus CE Marking for worldwide compliance. With a 6-inch touch screen display and a 480 Vac power supply, it supports scalable energy monitoring in modern control architectures. In practice, the PXMP-MB-2C-D translates to faster deployment, reduced wiring complexity, and clearer energy data for industrial power management and cost control.
Product Information
Extended Description
PXMP-MB-2C-D Eaton: Eaton enclosed meter, PXMP(MB,No Modules),NEMA12(600V),PXMP-DISP(6-XV),3Phase/4Wire Main Fuse Disconnect,Vdc Power Supply
Product Name
Eaton enclosed meter
Catalog Number
PXMP-MB-2C-D
UPC
786685763293
Product Length/Depth
12 in
Product Height
30 in
Product Width
23.63 in
Product Weight
100 lb
Compliances
CE Marked
Certifications
ANSI/IEEE Std C12.20 (0.2% accuracy) ANSI/IEEE Std C62.41 IEC 687 (0.2% accuracy)
Power supply
480 Vac
Wattage
60W
Phase
Three-phase
Display
6" Touch Screen
Degree of protection
NEMA 12
Meter type
PXMP
Eaton's enclosed meter family
Eaton's enclosed meter family
Eaton's Enclosed Meters
Eaton Specification Sheet - PXMP-MB-2C-D
Feature → Business Impact → Application: The PXMP-MB-2C-D uses a rugged NEMA 12 enclosure, protecting sensitive meters from dust and moisture in industrial environments, which reduces maintenance downtime and extends service life in manufacturing and process plants. This protection enables reliable continuous monitoring of three-phase systems in harsh settings, aligning with energy-management strategies and compliance reporting. Feature → Business Impact → Application: A built-in 6-inch touch screen display provides intuitive local access to metering data, accelerating commissioning, troubleshooting, and operator training across control rooms and field installations. This reduces engineering hours and speeds up fault isolation in data centers and HVAC installations. Feature → Business Impact → Application: The meter supports a 480 Vac power supply and 60 W wattage, ensuring compatibility with standard industrial distribution panels while delivering accurate data for load analysis, peak shaving, and energy audits. Feature → Business Impact → Application: ANSI/IEEE C12.20 (0.2% accuracy), ANSI/IEEE C62.41, and IEC 687 certifications, plus CE marking, minimize regulatory risk and simplify cross-border projects in manufacturing, utilities, and automation environments. Feature → Business Impact → Application: The PXMP-MB-2C-D’s PXMP meter type and three-phase/four-wire topology enable scalable integration with Eaton’s power-management ecosystem, supporting remote monitoring, data logging, and commissioning workflows for updated energy-management systems.
Get a Quick Quote for a Eaton PXMP-MB-2C-D
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton PXMP-MB-2C-D?
Enquire Now
FAQs
Install the PXMP-MB-2C-D within a standard NEMA 12 enclosure, ensuring proper mounting to support vibration and stray magnetic fields. Connect the three-phase, four-wire inputs and the 480 Vac supply as specified, then configure the 6-inch touch screen interface for site-specific metering points. The enclosure provides protection against dust and wash-down environments, reducing maintenance and enabling reliable long-term operation.
The PXMP-MB-2C-D is CE marked and certified under ANSI/IEEE Std C12.20 (0.2% accuracy), ANSI/IEEE Std C62.41, and IEC 687 (0.2% accuracy). These certifications support regulatory compliance across regional deployments and simplify qualification for energy-management projects in manufacturing, utilities, and data centers.
Key specs include a 480 Vac power supply, 60 W wattage, three-phase/four-wire configuration, a 6-inch touch screen display, and a NEMA 12 degree of protection. The PXMP meter type ensures accurate energy measurement across industrial loads, with standard UP disclosure and compatibility with Eaton’s power-management ecosystem.
Yes. The PXMP-MB-2C-D is designed for industrial applications with up to 600 V capability, aligning with NEMA 12 enclosure protection and three-phase distribution. It provides reliable metering data for high-voltage industrial panels and supports energy-management initiatives without compromising safety or accuracy.
The PXMP-MB-2C-D delivers precise energy measurements (0.2% accuracy per standards), reducing billing disputes and enabling accurate energy accounting. Its intuitive 6-inch display speeds commissioning, while CE and ANSI/IEEE certifications minimize regulatory risk and support faster project approvals, delivering cost savings through improved energy visibility and reduced downtime.
