Eaton QHCX3080H Miniature Circuit Breaker - 42 kAIC UL Listed
Part Number: QHCX3080H
Quick Summary
The Eaton QHCX3080H miniature circuit breaker is a thermal-magnetic protective device designed for industrial control panels and machine wiring. It delivers reliable overload and short-circuit protection in a compact, three-pole form factor, reducing space while guarding critical networks. Engineers often face nuisance trips or slow response on high-inrush equipment; this unit’s thermal-magnetic trip curve balances sensitivity with selectivity to minimize downtime. The QHCX3080H carries UL Listed and CSA Certified ratings, ensuring compliance across North American installations. With a 3-pole, 240 V design and an 80 A rating, it supports three-phase feeders while maintaining safe, predictable protection. Its cable-in/cable-out termination and modest 2.9 in depth simplify field wiring and panel layout, delivering faster installation and lower total cost of ownership.
Product Information
Extended Description
QHCX3080H Eaton: Eaton Quicklag Type QHCX Industrial Miniature Thermal-Magnetic Circuit Breaker,Miniature circuit breaker,80 A,42 kAIC,Three-pole,240 V,Thermal-magnetic,Cable-in/cable-out,QHCX,Non-interchangeable
Product Name
Eaton QC thermal magnetic circuit breaker
Catalog Number
QHCX3080H
UPC
786679009390
Product Length/Depth
2.9 in
Product Height
3.5 in
Product Width
3.4 in
Product Weight
1 lb
Warranty
1 year
Certifications
CSA Certified UL Listed
Circuit breaker type
QHCX
Connection
Cable-in/cable-out
Number of poles
Three-pole
Type
Miniature circuit breaker
Amperage Rating
80 A
Interrupt rating
42 kAIC
Trip Type
T268
Voltage rating
240 V - 240 V
Options
Non-interchangeable
Feature: Thermal-magnetic protection provides fast, coordinated trip for overloads and short circuits → Business Impact: Reduces unplanned downtime and improves equipment uptime by delivering predictable clearing without nuisance trips → Application: Ideal for industrial panel builds and machine controls that demand reliable overcurrent protection. Feature: 42 kAIC interrupt rating delivers high fault current handling → Business Impact: Enhances system safety and conductor protection in heavy-load environments, minimizing damage and downtime → Application: Suitable for feeders and three-phase circuits in manufacturing lines. Feature: Three-pole, 80 A rating for 240 V systems → Business Impact: Supports balanced protection across all phases with compact footprint, enabling tighter panel layouts → Application: Three-phase motors, conveyors, and process equipment. Feature: Cable-in/cable-out termination simplifies wiring → Business Impact: Reduces field labor and wiring errors, accelerating installation and serviceability → Application: New panel builds and retrofit projects in control cabinets. Feature: Compact dimensions and lightweight design (2.9 in depth, 3.5 in height, 3.4 in width, ~1 lb) → Business Impact: Easier mounting and wiring in space-constrained panels, lowering installation time and labor costs → Application: OEM equipment enclosures and distribution panels. Feature: UL Listed and CSA Certified → Business Impact: Ensures regulatory compliance and process safety across North American facilities → Application: Industrial automation, packaging lines, and processing equipment requiring certified protection.
