Eaton QPHW2020S Industrial Circuit Breaker - UL Listed
Part Number: QPHW2020S
Quick Summary
The Eaton QPHW2020S is a thermal-magnetic circuit breaker designed to protect industrial power feeds and control panels. Nuisance trips and difficult fault isolation slow production, increase downtime, and erode overall equipment effectiveness. UL Listed and CSA Certified with HACR ratings meet strict electrical standards, while its 22 kAIC interrupt rating supports heavy startup surges. With 120/208/240 V compatibility and plug-on mounting, it delivers quick installation, reliable protection, and scalable use across automation projects. Designed for two-pole configurations, it fits compact spaces while preserving easy diagnostic access for maintenance teams. This model supports standard Quicklag series with non-interchangeable options, delivering predictable, compliant performance across demanding environments.
Product Information
Extended Description
QPHW2020S Eaton: Eaton Quicklag Type QPH Industrial Thermal-Magnetic Circuit Breaker,Industrial circuit breaker,20 A,22 kAIC,Two-pole,120/208/240 V,Thermal-magnetic,Q7,QPHW,Non-Interchangeable,120/208/240V
Product Name
Eaton Quicklag thermal magnetic circuit breaker
Catalog Number
QPHW2020S
UPC
782116123148
Product Length/Depth
3 in
Product Height
2 in
Product Width
3 in
Product Weight
0.8 lb
Warranty
1 year
Compliances
HACR Rated
Certifications
UL Listed CSA Certified
Circuit breaker type
QPHW
Mounting Method
Plug-on
Number of poles
Two-pole
Shunt trip
120-240V
Type
Industrial circuit breaker
Amperage Rating
20 A
Interrupt rating
22 kAIC
Trip Type
T268
Voltage rating
120V or 120/240V
Options
Non-Interchangeable
Quantity
7
Special features
120/208/240 Vac shunt trip
With a 20 A rating and a 22 kAIC interrupt capacity, the QPHW2020S provides precise overload protection for motor feeders and control circuits. This minimizes nuisance trips and speeds fault isolation, reducing downtime in automation lines such as assembly, packaging, and material handling. The two-pole, thermal-magnetic design delivers reliable protection without sacrificing control performance. Plug-on mounting simplifies installation and panel integration, reducing wiring complexity and field terminations. Compatibility with standard panels and the Eaton Quicklag family shortens commissioning times and lowers labor costs, especially during retrofit projects. The built-in shunt trip supports 120-240 V remote actuation for emergency stops and safety interlocks. This capability improves safety compliance in critical lines such as conveyors and robotic cells, enabling rapid de-energization during faults. HACR-rated performance ensures suitability for HVAC controls, simplifying design and reducing separate protection devices. UL Listed and CSA Certified with a one-year warranty provide regulatory assurance and lifecycle predictability. The rugged construction, lightweight footprint, and 120/208/240 V shunt-trip option support scalable protection across multiple lines, while the 22 kAIC rating aligns with common industrial power distributions.
Get a Quick Quote for a Eaton QPHW2020S
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton QPHW2020S?
Enquire Now
FAQs
Install the QPHW2020S using the plug-on mounting method for rapid panel integration. Ensure the two-pole package aligns with the panel's bus and space constraints, then connect the 120/208/240 V shunt-tripp line if remote actuation is required. Verify the 20 A rating and 22 kAIC interrupt capacity are suitable for the protected circuit, and perform a functional test after wiring.
Key specs include a 20 A amperage rating, 22 kAIC interrupt capacity, 120 V or 120/240 V operation, and a two-pole configuration. The unit supports 120-240 V shunt trip and has HACR rating for HVAC/motor control circuits. This combination delivers reliable overload protection while accommodating standard industrial power distributions.
Yes. The QPHW2020S is designed for 120/208/240 V environments and offers a two-pole, plug-on configuration suitable for compact control panels. Its interrupt rating and thermal-magnetic trip provide dependable protection for motors and feeders in automation systems, while the shunt-trip option enhances remote safety capabilities in critical applications.
The device is UL Listed and CSA Certified, with HACR-rated performance. These certifications indicate compliance with North American electrical safety standards and suitability for HVAC-related loads, reducing risk during audits and easing procurement for regulated facilities. This credibility supports smoother regulatory approvals and supplier qualification.
The QPHW2020S can lower total cost of ownership through reduced nuisance trips, faster fault isolation, and easier installation thanks to plug-on mounting. Its compact form factor and compatibility with existing Quicklag components simplify stocking and maintenance. Combined with UL CSA certifications and reliable protection, this translates to less downtime and more predictable maintenance budgets.
