Eaton QPHW2070 Quicklag breaker - UL Listed & CSA Certified
Part Number: QPHW2070
Quick Summary
The Eaton QPHW2070 Quicklag thermal magnetic circuit breaker protects industrial circuits in control panels and machinery. Engineers often struggle with nuisance trips and slow fault isolation in rugged environments. UL Listed and CSA Certified with HACR rating support reliable protection for HVAC and motor circuits. With plug-on mounting and a 70 A rating at 120/240 V, it delivers fast, scalable protection while reducing panel space, installation time, and lifecycle costs. The device's 22 kAIC interrupt rating provides fast clearing of faults on high-energy lines, supporting uptime in demanding applications. This combination of ratings ensures compliance with industry standards while enabling designers to simplify protection schemes.
Product Information
Extended Description
QPHW2070 Eaton: Eaton Quicklag Type QPH Industrial Thermal-Magnetic Circuit Breaker,Industrial circuit breaker,70 A,22 kAIC,Two-pole,120/240 V,Thermal-magnetic,Q7,QPHW,Fixed,Non-Interchangeable
Product Name
Eaton Quicklag thermal magnetic circuit breaker
Catalog Number
QPHW2070
UPC
786679387221
Product Length/Depth
3.2 in
Product Height
2.1 in
Product Width
3.2 in
Product Weight
0.7 lb
Warranty
1 year
Compliances
HACR Rated
Certifications
UL Listed CSA Certified
Circuit breaker type
QPHW
Mounting Method
Plug-on
Number of poles
Two-pole
Terminals
Fixed
Type
Industrial circuit breaker
Amperage Rating
70A
Interrupt rating
22 kAIC
Trip Type
T268
Voltage rating
120/240 V
Options
Non-Interchangeable
Quantity
7
Feature: Thermal-magnetic protection combines instantaneous magnetic tripping with a thermal element for overload sensing → Business Impact: Reduces nuisance trips while delivering fast fault clearance, protecting motors and drives from damage → Application: Ideal for 70 A motor circuits, feeders, and HVAC controls in manufacturing lines. Feature: 22 kAIC interrupt rating and 120/240 V capability → Business Impact: High-energy fault handling supports safe shutdown and uptime in harsh environments → Application: Main feeders and machine panels powering 120/240 V equipment across automation lines. Feature: Two-pole design with fixed terminals and plug-on mounting → Business Impact: Simplifies installation, minimizes wiring errors, and speeds field replacement → Application: Retrofit projects and new builds in control panels with standard Eaton QPH components. Feature: HACR rated and UL Listed with CSA Certified → Business Impact: Codes and safety compliance are satisfied with a single device, improving audit readiness and warranty validation → Application: HVAC equipment circuits and general industrial protective schemes. Feature: Compact footprint and light weight (3.2 in L × 3.2 in W × 2.1 in H, 0.7 lb) → Business Impact: Reduces panel space requirements, simplifies logistics, and lowers installation labor → Application: Environments with limited panel depth and dense wiring in automation facilities. Feature: 1-year warranty and non-interchangeable option → Business Impact: Predictable support and reduced lifetime risk on critical lines → Application: Reliable protection in continuous operation plants and replacement capacity in maintenance cycles.
Get a Quick Quote for a Eaton QPHW2070
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton QPHW2070?
Enquire Now
FAQs
The QPHW2070 uses plug-on mounting with fixed terminals and two poles, designed for straightforward field installation in control panels. It supports 120/240 V circuits and a 70 A rating, enabling quick replacement and reliable performance in dense panel layouts.
Key ratings include 70 A continuous amperage, 22 kAIC interrupt capacity, two-pole configuration, and a voltage rating of 120/240 V. The trip type is T268, and it features fixed terminals with plug-on mounting to simplify wiring and protection coordination.
Yes. It is HACR rated and UL Listed with CSA Certification, making it suitable for HVAC equipment circuits and motor feeders common in industrial environments. This combination supports compliance and reliable motor protection in challenging conditions.
Yes. The device is UL Listed and CSA Certified, with HACR rating for HVAC and motor applications. These certifications help streamline compliance, audits, and installation acceptance in regulated industrial settings.
The QPHW2070 carries a 1-year warranty, offering predictable support and lower risk for maintenance budgeting. Its rugged thermal-magnetic design provides long-term protection with reduced nuisance trips, contributing to lower downtime and improved uptime metrics in production environments.
