Eaton RDF800L-3 RDF fused rotary disconnect switch - 600Vac
Part Number: RDF800L-3
Quick Summary
The Eaton RDF fused rotary disconnect switch isolates power in high-current electrical panels and motor control centers. Engineers often confront unreliable isolation in compact switchgear, risking arc flash exposure during maintenance. RoHS compliant and designed for rugged industrial use, the RDF800L-3 emphasizes safety and reliability in demanding environments, while supporting front-handle operation for safer manual disconnection. This solution integrates 800A rating with a 600 Vac/600 Vdc capability, offering a clear path to compliant, cost-effective protection in switchgear, MCCs, and distribution panels. By combining robust protection with straightforward installation, it helps reduce downtime and simplify procurement for power distribution projects.
Product Information
Extended Description
RDF800L-3 Eaton: Eaton Bussmann series RDF fused rotary disconnect switch, Standard switch, Front handle operation, 600 Vac, 600 Vdc, 800A, Fused disconnect switch - RDF800L-3
Product Name
Eaton Bussmann series RDF fused rotary disconnect switch
Catalog Number
RDF800L-3
UPC
051712402897
Product Length/Depth
14.5 in
Product Height
12.5 in
Product Width
1 in
Product Weight
39.2 lb
Warranty
Not Applicable
Compliances
Not Applicable RoHS Compliant
Amperage Rating
800A
Voltage rating
600 Vac, 600 Vdc
Operating temperature - max
70 °C
Operating temperature - min
-20 °C
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - RDF800L-3
Feature: 800A amperage rating → Business impact: Enables reliable isolation for heavy motor loads and high-current circuits, reducing risk and downtime in critical equipment. Application: Suitable for switchgear and MCC installations where continuous high-current switching is required. Feature: Fused RDF design → Business impact: Provides fuse-based protection to limit fault energy and protect downstream circuitry, improving overall system reliability. Application: Ideal for upstream protection in 600 Vac/600 Vdc systems. Feature: Front handle operation → Business impact: Enhances operator safety by enabling quick, visible isolation with minimal reach or tool requirements. Application: Maintenance-safe disconnects in compact enclosures. Feature: 14.5 in length, 12.5 in height, 1 in width, 39.2 lb → Business impact: Predictable footprint and weight support hassle-free mounting and serviceability in standard racks. Application: Enclosures with defined space constraints. Feature: RoHS compliant → Business impact: Reduces hazardous material concerns and eases regulatory compliance, supporting green initiatives. Application: Corporate sustainability programs and regulated installations. Feature: 600 Vac, 600 Vdc rating → Business impact: Dual-voltage capability expands compatibility across mixed voltage systems, simplifying procurement. Application: Industrial plants with mixed AC/DC distribution.
