Eaton RES-6 Fuse - 10 kAIC at 250 Vac
Part Number: RES-6
Quick Summary
Eaton RES-6 fuse provides time-lag protection for electrical circuits in industrial and commercial applications. Many engineers struggle with nuisance trips and downtime when protection is misapplied or hard to source. Critical considerations include class H protection and a high interrupt rating, while the non-indicating design minimizes panel clutter. This solution aligns with the need for robust time-delay protection in electrical protection and circuit control, delivering reliability, ease of sourcing, and consistent performance across industrial installations.
Product Information
Extended Description
RES-6 Eaton: Eaton Bussmann series RES fuse, time lag, non current-limiting, Industrial and commercial structures, 6 A, Class H, Non-indicating, 10 kAIC at 250 Vac, Standard, 10, 600 V
Product Name
Eaton Bussmann series RES fuse
Catalog Number
RES-6
UPC
051712110068
Product Length/Depth
5 in
Product Height
0.81 in
Product Width
0.81 in
Product Weight
0.18 lb
Warranty
Not Applicable
Compliances
Not Applicable
Amperage Rating
6 A
Interrupt rating
10 kAIC at 250 Vac
Voltage rating
600 V
Packaging type
Standard
Class
Class H
Fuse indicator
Non-indicating
Quantity
10
Special features
Super lag, time lag, non current-limiting
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - RES-6
The RES-6 fuse uses time-lag protection, which reduces nuisance tripping during motor start-up and short transient inrush events, delivering real-world uptime benefits and lower maintenance costs in industrial environments. This translates to improved system availability and predictable protection for feeders and controls, especially in manufacturing lines, HVAC units, and lighting assemblies that experience brief overloads. Its 6 A rating paired with a 600 V voltage rating and a 10 kAIC interrupt capacity at 250 Vac provides robust fault isolation while safeguarding adjacent equipment, improving safety compliance and reducing the risk of collateral damage. The Class H, non-indicating design minimizes visual inspections in high-density panels, supporting quick field servicing without false indicators and enabling cleaner, more durable control cabinets. With a compact 5 in length and standard packaging of 10 pieces, installation is straightforward and stocking is efficient for procurement teams. Compatibility with Eaton Bussmann series holders and standard fuse blocks ensures a smooth retrofit or panel upgrade, reducing engineering time and assuring coordinated protection across the system. In practice, this fuse helps facilities managers meet reliability targets and maintain uptime without sacrificing protection margins or service life.
