Eaton RM60060-1CHR Modular Fuse Block - 200 kAIC
Part Number: RM60060-1CHR
Quick Summary
Eaton RM60060-1CHR modular fuse block provides reliable overcurrent protection for DIN-rail panels in industrial controls. Designers often struggle with limited space and unpredictable fault currents, making protection hard to fit into compact panels. This 1P unit delivers a compact, 60 A solution with a 200 kAIC interrupt rating, ensuring fast clearing of faults. It carries RoHS compliance and PED 97/23 EC certification, enabling global deployment and regulatory alignment across markets. The product features box lug connections, DIN rail mounting, and a Class R fuse, delivering quick assembly, easy maintenance, and predictable performance in demanding automation environments.
Product Information
Extended Description
RM60060-1CHR Eaton: Eaton Bussmann Series RM modular fuse block, Box lugs with hex screws, 60 A, 1P, 200 kA RMS symm, 120°C, 50 lb-in max, Class R, CVR(I)-RH-60060, Black, Box lug, 200 kAIC, 75 °C, Stranded, Panel, DIN rail, 600 V, #2-14 AWG
Product Name
Eaton Bussmann Series RM modular fuse block
Catalog Number
RM60060-1CHR
UPC
051712621014
Product Length/Depth
1.5 in
Product Height
8 in
Product Width
1.5 in
Product Weight
0.25333333 lb
Warranty
Not Applicable
Compliances
RoHS Compliant
Certifications
ARO European Pressure Equipment Directive (PED) 97 /23 EC
Amperage Rating
60 A
Impulse withstand voltage
200 kA RMS symmetrical
Interrupt rating
200 kAIC
Short-circuit rating
200 kA RMS symmetrical
Torque rating
50 lb-in maximum
Voltage rating
600 V
Color
Black
Conductor material rated for
Both
Conductor temperature rating
75 °C
Conductor type
Stranded
Fuse type
Class R
Number of Poles
Single-pole
Operating temperature - max
120 °C
Operating temperature - min
120 °C
Wire size
#2-14 AWG
Accessories
CVR(I)-RH-60060
Connection
Box lug
Mounting method
DIN rail Panel
Special features
Box Lugs with Hex Screws
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - RM60060-1CHR
Feature: 60 A amperage rating. Business Impact: Protects control circuits from overload while enabling compact panel layouts. Application: Ideal for single-pole installations in space-constrained DIN rail panels. Feature: 200 kA RMS interrupt rating. Business Impact: Reduces fault energy exposure and wear on downstream devices. Application: Suitable for high-short-circuit environments in machine controls. Feature: 600 V voltage rating. Business Impact: Supports a wide range of automation circuits with safety margin. Application: Common in industrial control cabinets and motor control centers. Feature: Box lug terminals with hex screws. Business Impact: Ensures secure, maintenance-friendly wiring and reduced torque variation. Application: Field wiring in harsh environments where vibration resistance matters. Feature: DIN rail mounting with panel compatibility. Business Impact: Simplifies retrofits and new installs, cutting installation time. Application: Standard in most control panels for easy MRO. Feature: Class R fuse type. Business Impact: Known protection class delivering predictable coordination with select fuses. Application: Critical for standards-compliant protection in control circuits. Feature: RoHS compliance and PED 97/23 EC certification. Business Impact: Enables global deployment with regulatory peace of mind. Application: Applies to multinational equipment builds and export-reliant projects. The combination of robust ratings, secure connections, and flexible mounting makes RM60060-1CHR a reliable choice for OEMs and systems integrators seeking efficiency, compliance, and long service life in demanding industrial environments.
Get a Quick Quote for a Eaton RM60060-1CHR
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton RM60060-1CHR?
Enquire Now
FAQs
Begin by mounting the RM60060-1CHR on a standard DIN rail in the protected control panel area. Ensure box lug terminals are accessible for wiring, then tighten hex screws to the specified torque (up to 50 lb-in). Use conductor sizes #2-14 AWG and verify the unit is clamped securely to minimize vibration. Confirm 60 A rating and 600 V compatibility for the protected circuit, and verify RoHS/PED compliance for your application.
The RM60060-1CHR provides a 60 A amperage rating, 600 V voltage rating, and a 200 kA RMS symmetrical interrupt rating (200 kAIC). It is designed for 1P operation with Class R fuse compatibility, supporting reliable protection for industrial control circuits and motor starter enclosures.
Yes. It is a 1P modular fuse block designed for DIN rail and panel mounting, featuring box lug terminals and a 60 A rating with a high interrupt capacity. Its RoHS compliance and PED certification make it appropriate for global deployment in industrial controls, automation panels, and machine wiring.
The RM60060-1CHR is RoHS compliant and carries PED 97/23 EC certification, ensuring suitability for European markets and global export. These certifications help streamline regulatory approvals for equipment used in industrial automation and control systems.
The design uses box lug terminals and hex screws for reliable, vibration-resistant wiring, reducing maintenance time during inspections. Its high interrupt rating minimizes fuse replacements after fault events, and the DIN rail/panel mounting simplifies upgrades and retrofits, resulting in lower total cost of ownership over the life of the automation system.
