Eaton RSMP11 Conduit Hub Plate - 2 Hubs, 1/2 in NEMA 3
Part Number: RSMP11
Quick Summary
Eaton RSMP11 Conduit Hub Plate provides a rugged mounting base for conduit terminations in industrial control panels. Engineers rely on consistent hub alignment and straightforward field installs to minimize downtime, and this plate delivers both. The design aligns with NEC/CEC standards, carries a NEMA 3 rating for protection in ordinary locations, and uses a feraloy iron alloy for lasting strength in demanding environments. By standardizing a 4-1/2 by 4 inch footprint with two 1/2 inch hubs, it reduces part variety and simplifies stocking. In addition, its compact form supports faster commissioning and lower installation costs across OEM builds and service projects.
Product Information
Extended Description
RSMP11 Eaton: Eaton Crouse-Hinds series RSM/RSS conduit hub plate, 4-1/2" x 4", Feraloy iron alloy, 2 hubs, 1/2" trade size
Product Name
Eaton Crouse-Hinds series RSM/RSS conduit hub plate
Catalog Number
RSMP11
UPC
782274597003
Product Length/Depth
3.5 in
Product Height
3.5 in
Product Width
1.5 in
Product Weight
1.01 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
NEMA Rating
3
Enclosure size
4-1/2" x 4"
Number of hubs
2
Trade size
1/2"
Material
Feraloy iron alloy
Crouse-Hinds series RS, RSM and RSS Junction Boxes catalog page
RS, RSM and RSS Junction Boxes UL certification
RS, RSM and RSS Junction Boxes UL certification
Eaton Specification Sheet - RSMP11
Feature: Two hubs and 1/2 inch trade size provide flexible conduit entry options. Benefit: Reduces the need for additional hub plates and adapters, cutting material costs and installation time. Application: Ideal for RS/RSM/RSS junction boxes in new builds or retrofit projects. Feature: Feraloy iron alloy construction. Benefit: Delivers robust mechanical strength and durability in tough industrial environments, improving enclosure reliability over the life of the system. Application: Panels in factory floors or outdoor installations where vibration and impact can occur. Feature: Compact 4-1/2" x 4" enclosure footprint with 3.5" length and height. Benefit: Fits standard enclosures and maintains clean, accessible conduit terminations, reducing misalignment risk. Application: OEM equipment, control panels, and service installations. Feature: NEC/CEC compliance and NEMA Rating 3. Benefit: Regulatory alignment for ordinary/non-hazardous locations, simplifying compliance audits and installation planning. Application: Industrial facilities needing robust yet compliant enclosure accessories. Feature: Two-hub design with UL-listed references and UPC traceability. Benefit: Accelerates procurement decisions, minimizes inventory, and ensures project traceability. Application: System integrators, distributors, and maintenance teams sourcing RSMP11 for multiple sites.
Get a Quick Quote for a Eaton RSMP11
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton RSMP11?
Enquire Now
FAQs
RSMP11 is designed for Eaton Crouse-Hinds RS, RSM, RSS junction boxes. It features two hubs at 1/2 inch trade size and a 4-1/2 by 4 inch mounting footprint. The plate uses feraloy iron alloy for strength and is sized to fit ordinary/non-hazardous locations per NEC/CEC, making it a versatile upgrade for enclosure builds.
RSMP11 complies with NEC/CEC standards and carries a NEMA 3 rating for protection in ordinary locations. It is suitable for ordinary/non-hazardous environments. UL certifications are available via listed documents in the downloads, supporting regulatory and audit requirements for industrial installations.
The product measures 3.5 inches in length, 3.5 inches in height, and 1.5 inches in width, with a weight of 1.01 pounds. It provides a 4-1/2 by 4 inch enclosure footprint and two 1/2 inch hubs, aligning with common RS/RSM/RSS configurations.
RSMP11 reduces material complexity by providing two hubs in a single plate, eliminating extra hub plates and adapters. Its compact footprint fits standard enclosures, speeding assembly. The feraloy iron alloy strengthens durability, reducing maintenance cycles and downtime, while UPC and catalog references streamline procurement and inventory management for OEMs and service teams.
Official documentation for RSMP11 is available in the downloads section: Eaton Specification Sheet RSMP11, UL certification reports, and the RS/RSM/RSS catalog page. These resources provide installation guidance, electrical ratings, and regulatory compliance details for engineering reviews and audits.
