Eaton S48M23S25CU Encapsulated Transformer - UL Listed
Part Number: S48M23S25CU
Quick Summary
Eaton S48M23S25CU is a general purpose encapsulated transformer that delivers reliable 25 kVA power for industrial control panels. In today’s plants, installation complexity, environmental exposure, and certification gaps can stall projects and raise costs. UL Listed with a NEMA 3R enclosure provides safety and ruggedness, while its indoor-outdoor compatibility supports a wide range of sites. By pairing copper windings with precise tap options, it helps protect critical equipment and simplify compliance, delivering dependable performance across power distribution and control systems. This model also aligns with our emphasis on durability, efficient installation, and long-term maintenance planning, making it a robust choice for engineers and procurement teams.
Product Information
Extended Description
S48M23S25CU Eaton: Eaton General purpose encapsulated transformer, EP, copper, NEMA 3R, 182, 60 Hz, single-phase, 480 V, 230 V, 2 at +2.5% FCAN, 4 at -2.5% FCBN, 115 °C rise, 25 KVA, indoor-outdoor, 572C
Product Name
Eaton General purpose encapsulated transformer
Catalog Number
S48M23S25CU
UPC
786680057861
Product Length/Depth
14.12 in
Product Height
23.31 in
Product Width
16.35 in
Product Weight
428 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
UL Listed
Coil material
Copper
Design
EP
Enclosure
NEMA 3R
Frame
182
Tap size
2 at +2.5% FCAN, 4 at -2.5% FCBN
Type
General-Purpose Encapsulated Transformer
Wiring connection
572C
Frequency rating
60 Hz
Phase
Single-phase
Primary voltage
480 V
Secondary Voltage
230 V
Temperature rise
115 °C rise
Volt ampere rating
25 kVA
Weathershield
Indoor-Outdoor
Commercial Distribution, Transformers, Volume 2, Tab 2
Eaton Specification Sheet - S48M23S25CU
Selling Policy 25-000 - Distribution and Control Products and Services
The S48M23S25CU delivers 25 kVA at 60 Hz from 480 V to 230 V, enabling mid-size loads in industrial panels with improved efficiency and reduced heat buildup. Copper windings minimize losses and extend transformer life, translating to lower operating costs and longer intervals between maintenance cycles in demanding environments. The NEMA 3R enclosure supports indoor-outdoor installations, eliminating the need for separate protective housings and speeding up site deployment, whether in factories or outdoor equipment enclosures. Tap settings—2 at +2.5% FCAN and 4 at -2.5% FCBN—offer precise voltage regulation to accommodate supply fluctuations, reducing voltage-related equipment wear and safeguarding sensitive controls. Weathershield compatibility further broadens where this transformer can live, streamlining procurement for mixed-site footprints. With UL Listed certification and a rugged 182 frame, it aligns with strict safety standards while fitting common mounting footprints, accelerating commissioning and reducing total installed cost. The combination of a 14.12 in length, 16.35 in width, and 23.31 in height helps engineers optimize panel real estate and maintain adequate clearances for heat dissipation. Finally, the 25 kVA rating supports robust power distribution and control architectures in manufacturing, water treatment, and process automation scenarios, delivering predictable performance with lower lifecycle risk.
