Eaton S60N11S02 Transformer - UL Listed Indoor-Outdoor
Part Number: S60N11S02
Quick Summary
Eaton S60N11S02 general-purpose encapsulated transformer delivers reliable voltage conversion for control panels and industrial equipment. In tight spaces and harsh facilities, panel-mounted transformers can struggle with mounting, weather exposure, and service accessibility, driving maintenance costs. UL Listed, NEMA 3R enclosure, and 60 Hz single-phase operation provide durable protection and predictable performance in indoor-outdoor installations. For procurement and engineering teams, the combination of a compact form factor, aluminum windings, and Eaton warranty translates to faster approvals, lower lifecycle cost, and less field rework. This model supports robust power distribution and streamlined maintenance in modern automation environments.
Product Information
Extended Description
S60N11S02 Eaton: Eaton General purpose encapsulated transformer, EP, aluminum, NEMA 3R, 68, 60 Hz, single-phase, 600 V, 120/240 V, NONE, 115 °C rise, 2 KVA, indoor-outdoor, 524B
Product Name
Eaton General purpose encapsulated transformer
Catalog Number
S60N11S02
UPC
786680048777
Product Length/Depth
6.52 in
Product Height
13.41 in
Product Width
6.37 in
Product Weight
42 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
UL Listed
Coil material
Aluminum
Design
EP
Enclosure
NEMA 3R
Frame
68
Tap size
None
Type
General-Purpose Encapsulated Transformer
Wiring connection
524B
Frequency rating
60 Hz
Phase
Single-phase
Primary voltage
600 V
Secondary Voltage
120/240 V
Temperature rise
115 °C rise
Volt ampere rating
2 kVA
Weathershield
Indoor-Outdoor
Commercial Distribution, Transformers, Volume 2, Tab 2
Eaton Specification Sheet - S60N11S02
Selling Policy 25-000 - Distribution and Control Products and Services
Feature: General-purpose encapsulated design with aluminum coil. Business Impact: Improves thermal efficiency, reduces weight and material cost, and enables easier handling during installation. Application: Ideal for space-constrained control panels in industrial automation and power distribution setups. Feature: 2 kVA rating with 600 V primary and 120/240 V secondary. Business Impact: Provides sufficient headroom for common machine loads, minimizing the need for multiple smaller transformers and improving panel density. Application: Machine tools, conveyors, and robotics systems in commercial and industrial facilities. Feature: NEMA 3R enclosure with indoor-outdoor weathershield. Business Impact: Enables reliable operation across indoor and outdoor locations with rain, dust, and temperature exposure. Application: Outdoor equipment cabinets and protected outdoor installations in harsh environments. Feature: 60 Hz, single-phase performance with 115 °C rise. Business Impact: Predictable performance and thermal management under typical facility loads, reducing overheating risk. Application: General purpose power conversion for control circuits and automation panels. Feature: UL Listed and 68 frame with 524B wiring. Business Impact: Simplifies compliance and wiring compatibility, accelerating approvals and serviceability. Application: Panel boards, distribution blocks, and Eaton catalog integration. Insight: Aluminum construction and compact dimensions support easier installation, maintenance, and lifecycle cost reduction in high-mupply, lean manufacturing environments.
Get a Quick Quote for a Eaton S60N11S02
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton S60N11S02?
Enquire Now
FAQs
The S60N11S02 is designed for straightforward panel mounting in standard enclosures. It features a 68 frame and a 524B wiring connection, with overall dimensions of 6.52 in depth, 13.41 in height, and 6.37 in width, enabling compatibility with many Eaton and third-party panels. Use the UL Listed rating and NEMA 3R enclosure to guide indoor-outdoor installations. Verify clearance for heat dissipation and secure mounting to a solid panel surface with appropriate fasteners.
Key specs include 2 kVA VA rating, 60 Hz frequency, single-phase configuration, 600 V primary, and 120/240 V secondary voltage. The transformer uses aluminum windings and supports an 115 °C rise, which informs thermal management and cooling requirements. This combination helps ensure reliable voltage conversion for load profiles typical in control panels and automation gear.
Yes, the S60N11S02 is rated for indoor-outdoor service with a NEMA 3R enclosure and Indoor-Outdoor weathershield. This configuration protects against moisture, dust, and temperature variations, enabling installation in exterior equipment rooms or weather-exposed locations while maintaining electrical integrity and safety.
Eaton provides a warranty under Selling Policy 25-000, offering one year from the date of installation or eighteen months from shipment, whichever comes first. This warranty supports field reliability and reduces downtime risk. For ongoing maintenance, refer to Eaton’s documentation and the specification sheet S60N11S02 for service guidance.
Official documentation includes the Eaton Specification Sheet S60N11S02 and the Commercial Distribution catalog volume with transformer data. You can also access the warranty guide Selling Policy 25-000. These documents provide detailed electrical ratings, wiring, installation notes, and compliance references to streamline approvals and engineering reviews.
