Eaton S60N11S76 Transformer - UL Listed, NEMA 3R
Part Number: S60N11S76
Quick Summary
Eaton S60N11S76 is a general-purpose encapsulated transformer for 120/240 V secondary outputs in industrial power systems. Facilities often struggle with rugged outdoor conditions and the need for reliable, low-maintenance power conversion. UL Listed safety certification, a NEMA 3R enclosure, and 60 Hz single-phase operation ensure compliance and outdoor readiness. This design supports efficient panel mounting and fast deployment in control cabinets and outdoor enclosures, aligning with Eaton's power-management ecosystem. This product aligns with standard control-cabinet practices, reduces inventory complexity with a universal 0.75 kVA footprint, and simplifies sourcing through UL-listed, NEMA 3R protection and Eaton's dedicated support. Backed by datasheets and field-service guidance, it speeds specification.
Product Information
Extended Description
S60N11S76 Eaton: Eaton General purpose encapsulated transformer, EP, aluminum, NEMA 3R, 60 Hz, single-phase, 600 V, 120/240 V, NONE, 115 °C rise, 0.75 KVA, indoor-outdoor
Product Name
Eaton General purpose encapsulated transformer
Catalog Number
S60N11S76
UPC
786685183909
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.001 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
UL Listed
Coil material
Aluminum
Design
EP
Enclosure
NEMA 3R
Tap size
None
Type
General-Purpose Encapsulated Transformer
Frequency rating
60 Hz
Phase
Single-phase
Primary voltage
600 V
Secondary Voltage
120/240 V
Temperature rise
115 °C rise
Volt ampere rating
0.75 kVA
Weathershield
Indoor-Outdoor
Feature: Encapsulated, general-purpose EP design. Business Impact: Delivers rugged protection against dust, moisture, and vibration, reducing maintenance and extending service life. Application: Ideal for control panels and outdoor enclosures in industrial facilities. Feature: Aluminum coil with epoxy encapsulation. Business Impact: Improves thermal performance while keeping weight low, easing handling and installation. Application: Compact switchgear and space-constrained panel boards. Feature: NEMA 3R enclosure with indoor-outdoor capability. Business Impact: Weather resistance minimizes environmental risk and warranty exposure. Application: Outdoor equipment, weather-exposed installations, and rugged control rooms. Feature: 60 Hz single-phase operation, 600 V primary, 120/240 V secondary. Business Impact: Aligns with standard plant power distribution, simplifying wiring, protection schemes, and spare parts. Application: Machine controls, lighting feeders, and control panels in factories. Feature: 0.75 kVA rating with 115 °C rise. Business Impact: Provides adequate load capacity with thermal headroom, reducing the need to oversize and lowering lifecycle costs. Application: Load centers, control circuits, and DC bus interfaces in automation lines. Feature: UL Listed certification and compatibility with Eaton ecosystem. Business Impact: Streamlined procurement, regulatory compliance, and access to comprehensive datasheets and support. Application: Cross-facility deployment where certified, interoperable transformers are required.
Get a Quick Quote for a Eaton S60N11S76
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton S60N11S76?
Enquire Now
FAQs
When installing the S60N11S76, ensure a compliant enclosure and adequate ventilation, with space for wiring terminals and accessibility for inspection. Use a mounting arrangement compatible with NEMA 3R-rated installations and observe clearances for heat dissipation. The unit’s 600 V primary and 120/240 V secondary voltages should be wired to appropriately rated protective devices and bus configurations for reliable operation.
Key specs include a 0.75 kVA VA rating, 60 Hz frequency, single-phase configuration, and a 600 V primary with 120/240 V secondary. Suitable loads are moderate-power control circuits, panel-board feeders, and automation equipment within typical industrial distributions. The transformer is designed to deliver clean, isolated power for sensitive controls while supporting standard industrial wiring practices.
Yes. The S60N11S76 features a NEMA 3R enclosure and indoor-outdoor weather tolerance, making it suitable for outdoor panels, switchgear, or equipment located in variable environments. Its aluminum coil, encapsulated construction, and UL safety certification further support reliable operation in outdoor installations while maintaining compatibility with indoor control systems.
The transformer is UL Listed, indicating compliance with recognized safety standards. It uses a NEMA 3R enclosure for weather resistance, supports 60 Hz single-phase operation, and is designed for indoor-outdoor use. These certifications help with regulatory compliance, insurance requirements, and simplifying procurement for regulated facilities.
The product carries Eaton’s warranty policy: one year from installation or eighteen months from shipment, whichever occurs first. Maintenance involves routine inspection of terminals, enclosure seals, and insulation integrity. ROI comes from reliable, low-maintenance operation, reduced downtime, and compatibility within Eaton’s power-management ecosystem, which simplifies sourcing, spares, and future upgrades.
