Eaton S84N11E10XCE Encapsulated Transformer - UL Listed
Part Number: S84N11E10XCE
Quick Summary
The Eaton S84N11E10XCE encapsulated transformer provides reliable single-phase power conversion for industrial control panels and equipment rooms. It addresses common plant challenges such as dust, moisture, and harsh mounting constraints by using a rugged encapsulated enclosure. UL Listed and CE Marked, with a NEMA 3R enclosure, ensure regulatory compliance and dependable operation in indoor or outdoor installations. Coupled with aluminum windings and a shielded design, the unit supports cost-effective deployment across automation architectures. In short, you gain reliable voltage conversion, robust protection, and regulatory peace of mind for scalable manufacturing operations. Engineers will appreciate its compatibility with 380-480V mains and 120/240V control circuits. This makes it a strong fit for retrofits and new builds alike.
Product Information
Extended Description
S84N11E10XCE Eaton: Eaton, general purpose encapsulated transformer, ep, single-phase, pv: 380/440 400/460 415/480v, taps: none, sv: 120/240v, 115°c, 10 kva, al windings, elec. shield, frame: 180, indoor-outdoor
Product Name
Eaton General purpose encapsulated transformer
Catalog Number
S84N11E10XCE
UPC
786680049583
Product Length/Depth
10.52 in
Product Height
19 in
Product Width
13.38 in
Product Weight
202 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
UL Listed
Catalog Notes
50/60 Hz, CE Marked
Coil material
Aluminum
Design
EP
Enclosure
NEMA 3R
Frame
180
Tap size
None
Type
General-Purpose Encapsulated Transformer
Wiring connection
590A
Frequency rating
50-60 Hz
Phase
Single-phase
Primary voltage
380 V, 400 V, 415 V, 440 V, 460 V, 480 V
Secondary Voltage
120/240 V
Temperature rise
115 °C rise
Volt ampere rating
10 kVA
Special features
Electrostatically shielded
Weathershield
Indoor-Outdoor
Feature: 10 kVA single-phase encapsulated transformer; Business Impact: provides dependable power for mid-size control loads while minimizing footprint and maintenance; Application: control panels and distributed automation hubs. The unit’s primary voltages span 380-480 V with a universal secondary of 120/240 V, reducing wiring complexity and inventory needs in mixed-voltage environments. Feature: Aluminum windings and electrostatic shield; Business Impact: improves thermal performance, EMI/EMC resilience, and longevity while keeping weight manageable; Application: equipment rooms and harsh manufacturing floors. Feature: 50-60 Hz compatibility and 115°C rise capability; Business Impact: supports continuous operation in typical plant electrical systems with predictable thermal margins; Application: process automation lines and machine tool systems. Feature: NEMA 3R enclosure enabling indoor-outdoor use; Business Impact: simplifies outdoor installations and retrofit projects by withstanding weather and dust ingress; Application: sealed or exposed areas without enclosure relocation. Feature: UL Listed and CE Marked; Business Impact: streamlines procurement, compliance, and cross-border deployments; Application: supplier audits and regulated industries. Feature: 10 kVA rating and robust frame 180; Business Impact: aligns with mid-cycle loads and retrofit strategies while maintaining mounting compatibility; Application: panel assemblies and stand-alone power conversion points.
Get a Quick Quote for a Eaton S84N11E10XCE
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton S84N11E10XCE?
Enquire Now
FAQs
Ensure a suitable mounting surface with adequate clearance for cooling, and place the unit in a protected location suitable for indoor or outdoor use. The enclosure is NEMA 3R rated for rugged environments, and the transformer uses 590A wiring connections. Allocate space for access, EMI considerations, and compliance with local electrical codes during panel fabrication.
The transformer delivers 10 kVA, is single-phase, and operates at 50–60 Hz. Primary voltages are 380, 400, 415, 440, 460, or 480 V, with a secondary of 120/240 V. Winding material is aluminum, and it features an electrostatic shield with a 115°C rise rating, suitable for general-purpose encapsulated applications.
Yes. Its encapsulated, shielded design combined with a NEMA 3R enclosure makes it appropriate for control panels and automation equipment in both indoor and outdoor installations. The 10 kVA rating supports a range of mid-size loads, while the 120/240 V secondary easily powers control circuits and auxiliary devices within a single rack or cabinet.
The unit is UL Listed and CE Marked, indicating compliance with safety and market regulations for North American and European markets. These certifications simplify supplier qualifications, support cross-border procurement, and help meet regulatory requirements for equipment installed in regulated facilities.
Maintenance is minimized by a durable encapsulated design, aluminum windings, and an EMI shield, which reduce field faults and routine servicing. The rugged enclosure enables longer service life in harsh environments, contributing to lower downtime and favorable total cost of ownership for mid-sized automation projects.
