Eaton SA101ZN Slotted Angle - 12 gauge UL Listed
Part Number: SA101ZN
Quick Summary
SA101ZN slotted angle from Eaton provides robust mounting support for B-Line steel channel systems in equipment racks and service enclosures. In tight electrical rooms and data centers, securing components quickly and accurately is essential, and precise-fit angles help prevent misalignment and fatigue. UL Listed certification, 12-gauge steel construction, and a zinc finish deliver long-term reliability in demanding environments. The green color supports field identification, while the 5 in height, 7.375 in length, and 7.35 in width enable flexible layouts and easier retrofits. Standardizing on Eaton slotted angles improves supply-chain reliability and simplifies maintenance across projects, delivering measurable reductions in installation time and on-site errors.
Product Information
Extended Description
SA101ZN Eaton: Eaton B-Line series slotted angle, 5" H x 7.3750" L x 7.35" W, Green, 12 gauge
Product Name
Eaton B-Line series slotted angle
Catalog Number
SA101ZN
UPC
781011860097
Product Length/Depth
7.375 in
Product Height
5 in
Product Width
7.35 in
Product Weight
67 lb
Certifications
UL Listed
Application
Steel channels
Special features
Zinc
Type
Connection plate
Color
Green
Material gauge
12 gauge
Feature → Business Impact → Application. 12 gauge steel with zinc finish provides corrosion resistance and structural rigidity, reducing replacement costs and downtime in harsh environments while enabling long-lasting support for steel channel installations in data centers and facilities. 5 in height, 7.375 in length, and 7.35 in width offer flexible fitment for compact racks and modular enclosures, improving layout efficiency and enabling faster MEP integrations. UL Listed certification ensures regulatory compliance and safer operation in industrial settings, supporting procurement requirements and reducing risk during audits. The green color aids field identification and circuit segregation, while the connection plate design simplifies mounting with standard hardware, cutting installation time and minimizing field customization. Compatibility with Eaton B-Line series channels enhances stock continuity and reduces vendor fragmentation across multi-site projects. Overall, this slotted angle delivers predictable performance, easier maintenance, and a lower total cost of ownership for channel-based support systems.
Get a Quick Quote for a Eaton SA101ZN
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton SA101ZN?
Enquire Now
FAQs
SA101ZN is designed for Eaton B-Line series slotted angles and aligns with standard slotted angle mounting plates used with the B-Line channel family. It supports common 12 gauge channel hardware and the catalog specifications confirm seamless integration across typical installations.
SA101ZN measures 5 in in height, 7.375 in in length, and 7.35 in in width, with a 12 gauge steel construction and a weight of approximately 67 lb. It is color coded green and UL Listed, with a zinc finish noted in the model features.
SA101ZN features a zinc finish and UL Listed rating for general industrial use, providing corrosion resistance relative to standard steel. However, there is no IP rating specified, so for prolonged outdoor exposure or immersion, verify environmental requirements and consider protective measures or alternatives with appropriate ingress protection.
Plan for a straightforward mounting using standard connection plates and hardware compatible with Eaton B-Line channels. The 12 gauge construction offers robust support, while the included dimensions guide layout planning. Properly labeling green identifiers can speed up future maintenance and rack reconfigurations, reducing field errors and downtime.
The ROI comes from faster, error-free installations due to precise dimensions and compatible hardware, reduced maintenance due to corrosion-resistant 12 gauge steel with zinc finish, and minimized inventory fragmentation by sticking to a single Eaton B-Line slotted angle family across multiple sites.
