Eaton SC-2 Fuse - Class G, 2 A, 600 Vac, 100 kAIC
Part Number: SC-2
Quick Summary
The Eaton SC-2 fuse protects control circuits with fast-acting current limiting for industrial equipment. Nuisance trips and downtime from undersized protection erode machine availability and inflate maintenance costs. RoHS compliant and CE marked, the Class G device is designed to withstand high fault currents while protecting wiring. This 2 A fuse delivers a 100 kAIC interrupt rating at 600 Vac and remains effective against DC transients up to 170 Vdc. For panel builders and OEMs, SC-2 offers reliable protection with ferrule-end connections, RoHS compliance, and straightforward sourcing within the Bussmann series. Its compact size and standard packaging simplify replacement and stocking.
Product Information
Extended Description
SC-2 Eaton: Eaton Bussmann Series Class G fuse, SC, fast-acting, current limiting fuse, 2 A, rejection style fuse, interrupting rating of 100 kA at 600 Vac and 10 kA at 170 Vdc
Product Name
Eaton Bussmann series SC fuse
Catalog Number
SC-2
UPC
051712250023
Product Length/Depth
1.31 in
Product Height
0.41 in
Product Width
0.41 in
Product Weight
0.1 lb
Warranty
Not Applicable
Compliances
RoHS Compliant CE Marked
Amperage Rating
2 A
Interrupt rating
100 kAIC at 600 Vac 10 kAIC at 170 Vdc
Voltage rating
600 Vac, 170 Vdc
Packaging type
Standard
Class
Class G
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Special features
Ferrule design, Type P
Low Voltage Branch Circuit Fuse Chapter
Low Voltage Branch Circuit Fuse Chapter
RoHS Search Tool
Bussmann series Fuseology
Eaton Specification Sheet - SC-2
Bussmann series Rejecting Fuses data sheet no. 1024
Bussmann series Rejecting Fuses data sheet no. 1024
Datasheet - FNQ-30
Feature: Class G fast-acting current-limiting protection. Business Impact: Rapid interruption reduces fault energy, minimizes insulation damage, and improves downstream equipment reliability. Application: Ideal for protecting control panels, PLC power feeds, and motor-control circuits in automated lines. Feature: 2 A amperage rating. Business Impact: Precise protection for small-draw circuits, reducing nuisance trips while maintaining safety margins. Application: Control circuitry, sensors, and logic circuits in machine automation. Feature: High interrupt rating of 100 kAIC at 600 Vac (and 10 kAIC at 170 Vdc). Business Impact: Superior fault tolerance for high-energy industrial environments; supports safe upstream protection coordination. Application: Main feeders and bus connections in automation panels. Feature: Ferrule end x ferrule end with ferrule design Type P. Business Impact: Reliable mechanical connection and proven vibration resistance; easier field installation and maintenance. Application: Standard wiring harnesses in control enclosures and panel assemblies. Feature: RoHS compliant and CE marked with a compact 1.31 in length and standard packaging. Business Impact: Regulatory readiness and easy sourcing reduce compliance risk and spare-part inventory. Application: Global deployments across OEMs and system integrators.
Get a Quick Quote for a Eaton SC-2
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton SC-2?
Enquire Now
FAQs
The SC-2 is a 2 A, Class G fast-acting current-limiting fuse with a 100 kAIC interrupt rating at 600 Vac (and 10 kAIC at 170 Vdc). It uses ferrule-end connections and is RoHS compliant and CE marked, making it suitable for standard control-panel protection, PLC power feeds, and small drive circuits in diverse industrial applications.
SC-2 uses ferrule-end connections with a ferrule design Type P, enabling reliable mechanical bonding and straightforward wiring in standard enclosures. It aligns with Bussmann series cataloging for easy sourcing and replacement, and its standard packaging supports fast stocking and field replacement in control panels and machine assemblies.
Yes. The SC-2 is RoHS compliant and CE marked, ensuring regulatory compliance for global deployments. This reduces compliance risk for panel builders and OEMs working in regions with strict environmental and safety standards while maintaining compatibility with standard European and global electrical practices.
SC-2 offers a high interrupt rating of 100 kAIC at 600 Vac and fast-acting performance, which minimizes fault energy and arc exposure. Its current-limiting characteristics protect downstream equipment, improve coordination with upstream protection, and reduce maintenance costs by lowering the likelihood of collateral damage in high-energy faults.
The SC-2 is ideal for control panels, automation cabinets, and machine-automation circuits in manufacturing and processing industries. Its combination of 2 A protection, Class G fast-acting performance, and ferrule-end connections makes it a robust choice for OEMs, system integrators, and panel builders seeking reliable protection for low-to-medium voltage circuits.
