Eaton SC-35 SC Fuse - 100 kAIC at 480 Vac, Class G
Part Number: SC-35
Quick Summary
SC fuse is Eaton's fast-acting current-limiting protection for control panels and motor circuits. Engineers and maintenance teams often battle nuisance trips and unexpected downtime from surge events; this fuse interrupts faults quickly while preserving critical loads. The device carries CE marking and RoHS compliance, aligning with widely adopted safety and environmental standards, and it belongs to the Class G family with ferrule-end design for rugged field use. For industrial automation environments, the SC-35 offers reliable electrical protection, straightforward installation, and predictable maintenance cycles—supporting safer operations and reduced total cost of ownership.
Product Information
Extended Description
SC-35 Eaton: Eaton Bussmann Series Class G fuse, SC, fast-acting, current limiting fuse, 35 A, rejection style fuse, interrupting rating of 100 kA at 480 Vac and 10 kA at 300 Vdc
Product Name
Eaton Bussmann series SC fuse
Catalog Number
SC-35
UPC
051712250351
EAN
5027590408424
Product Length/Depth
0.41 in
Product Height
2.25 in
Product Width
0.41 in
Product Weight
0.35 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Amperage Rating
35 A
Interrupt rating
100 kAIC at 480 Vac 10 kAIC at 300 Vdc
Response time
12 sec at 200%
Voltage rating
480 Vac, 300 Vdc
Packaging type
Standard
Class
Class G
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Special features
Ferrule design, Type P
Bussmann Full Line Catalog
Bussmann Full Line Catalog
RoHS Search Tool
Bussmann series Fuseology
Bussmann series Rejecting Fuses data sheet no. 1024
Feature: 35 A amperage rating provides robust overload protection for typical control circuits and small motor starters. Business impact: this level of protection reduces thermal stress on upstream devices and minimizes nuisance trips that interrupt production. Application: ideal for branch circuits in industrial control panels and machinery where steady current-limiting is essential.Feature: 100 kAIC interrupt rating at 480 Vac; 10 kAIC at 300 Vdc enables high-energy fault handling. Business impact: fault currents are interrupted quickly and safely, limiting damage to transformers, drives, and wiring. Application: suitable for heavy industrial feeders, machine tools, and power distributions subject to short-circuit events.Feature: Voltage ratings of 480 Vac and 300 Vdc with a 12-second response time at 200%. Business impact: supports selective coordination and controlled fault clearance to protect critical circuits. Application: control power rails, motor drives, and DC-bus protection in mixed AC/DC environments.Feature: Ferrule end x ferrule end with Type P ferrule design and non-indicating status. Business impact: simplifies field installation with reliable terminations and reduces mis-insertion risk in panel assemblies. Application: compatible with ferrule-based Bussmann holders and standard panel feeders in industrial environments.Feature: CE Marked and RoHS compliant. Business impact: regulatory alignment streamlines procurement, audits, and global deployment while meeting environmental standards. Application: industries requiring environmental compliance and product safety for electrical protection components.
Get a Quick Quote for a Eaton SC-35
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton SC-35?
Enquire Now
FAQs
SC-35 ferrule-end fuses install into compatible Bussmann series holders using ferrule terminations. Confirm the holder supports a Class G, fast-acting, current-limiting fuse and use proper crimping or ferrule tooling for a reliable termination. The rejection-style design prevents incorrect insertion and ensures correct slotting in control panels, cabinets, and machine enclosures, reducing field service calls.
SC-35 specifications include a 35 A amperage rating, 100 kAIC interrupt rating at 480 Vac, and 10 kAIC at 300 Vdc. It is rated for 480 Vac and 300 Vdc, with a 12-second response time at 200% of rated current. These parameters support fast fault clearance and protection of upstream components in both AC and DC circuits.
Yes. The SC-35 carries CE marking and RoHS compliance, meeting European safety and environmental requirements. This simplifies procurement for regulated projects and supports global deployment across facilities while assuring regulatory alignment for electrical protection components.
SC-35 is well-suited for control panels, motor circuits, and branch protection in industrial automation environments. Its 35 A rating, high interrupt capacity, and ferrule ends support reliable protection in manufacturing lines, packaging equipment, and conveyors. The fast-acting, current-limiting design minimizes energy let-through and supports safer, more predictable operation.
Warranty for the SC-35 is Not Applicable per the datasheet. For maintenance, plan to replace with the same model SC-35 when faults occur, inspect ferrule terminations for damage, and follow standard safe-disconnect procedures. Regularly review protection settings against system changes to maintain proper protection coordination and minimize downtime.
