Eaton SC-45 Fuse - Class G Rejection Style, Fast-Acting
Part Number: SC-45
Quick Summary
Eaton Bussmann SC fuse provides 45 A fast-acting overcurrent protection for industrial control panels. This design helps prevent nuisance trips while safeguarding sensitive circuitry, reducing unplanned downtime. The fuse is CE marked and RoHS compliant, aligning with European safety and environmental standards. Its compact footprint, high interrupt ratings, and proven reliability simplify panel design and procurement. By integrating Bussmann's Class G current-limiting technology within Eaton's trusted ecosystem, you gain consistent performance, easier stocking, and regulatory peace of mind for mission-critical equipment.
Product Information
Extended Description
SC-45 Eaton: Eaton Bussmann Series Class G fuse, SC, fast-acting, current limiting fuse, 45 A, rejection style fuse, interrupting rating of 100 kA at 480 Vac and 10 kA at 300 Vdc
Product Name
Eaton Bussmann series SC fuse
Catalog Number
SC-45
UPC
051712250450
EAN
5027590066389
Product Length/Depth
0.41 in
Product Height
2.25 in
Product Width
0.41 in
Product Weight
0.35 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Amperage Rating
45 A
Interrupt rating
100 kAIC at 480 Vac 10 kAIC at 300 Vdc
Response time
12 sec at 200%
Voltage rating
480 Vac, 300 Vdc
Packaging type
Standard
Class
Class G
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Special features
Rejection style
Bussmann Full Line Catalog
Bussmann Full Line Catalog
RoHS Search Tool
Bussmann series Fuseology
Bussmann series Rejecting Fuses data sheet no. 1024
The 45 A Class G current-limiting SC fuse delivers fast-acting protection that minimizes arc exposure and downstream damage, boosting overall equipment reliability and reducing repair costs in control panels and machine enclosures. In practice, this translates to fewer interruption events and shorter downtime during overloads, supporting predictable maintenance schedules and safer start-up sequences in automated lines. The 100 kAIC interrupt rating at 480 Vac and 10 kAIC at 300 Vdc provides robust fault-current clearance for high-energy circuits, enabling safe operation of motors, drives, and power supplies while meeting industry safety expectations. Rejection style construction prevents incorrect substitutions, improving inventory control and field reliability in complex panel assemblies. Ferrule end x ferrule end connections simplify termination with standard crimp practices, delivering faster, cleaner installations and reduced field wiring errors. The fuse’s compact dimensions (0.41 in W/D, 2.25 in H) and 0.35 lb weight support easy mounting in crowded enclosures, preserving panel real estate. Non-indicating status helps keep control indicators uncluttered in diagnostic-rich environments, while CE Marked and RoHS compliant features support global compliance programs and sustainability goals.
Get a Quick Quote for a Eaton SC-45
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton SC-45?
Enquire Now
FAQs
SC-45 uses ferrule end x ferrule end terminals, designed for quick, secure crimp connections in standard control panels. Its compact 0.41 in width and 2.25 in height fit tight enclosures, while the 0.35 lb weight minimizes panel load. Installing this fuse with compatible ferrule terminals reduces wiring errors and speeds up commissioning in industrial environments.
SC-45 provides a 100 kAIC interrupt rating at 480 Vac and 10 kAIC at 300 Vdc, enabling safe interruption of high-energy faults. Its fast-acting, current-limiting design helps constrain fault current to protect downstream components, reducing damage to transformers, drives, and control electronics and shortening downtime after a fault condition.
Yes. The SC-45 is rated for 480 Vac and 300 Vdc circuits, with a 45 A amperage rating. This makes it appropriate for industrial control panels and machines that operate across both AC and DC supply rails, providing consistent protection across mixed systems while maintaining a compact form factor.
SC-45 is CE marked and RoHS compliant, ensuring compliance with European safety and environmental requirements. This helps streamline regulatory approvals for panels shipped to Europe and supports sustainability goals by restricting hazardous substances, aligning with broader corporate compliance initiatives.
SC-45 reduces downtime by rapidly interrupting overloads and limiting fault currents, protecting downstream equipment and extending component life. Its rejection-style design minimizes mis-parts in stocking, while ferrule terminations speed installation. Together with a compact footprint and global availability, it lowers maintenance costs and supports faster root-cause analysis in automated facilities.
