Eaton SC-6 Fuse - Class G 100 kAIC at 600 Vac
Part Number: SC-6
Quick Summary
Eaton SC-6 fuse provides fast-acting circuit protection for industrial power systems in control panels and machinery. Operators and engineers often battle nuisance trips and undersized protection that disrupts production. RoHS compliant construction supports safe deployment in regulated facilities while maintaining high reliability. With a Class G designation and current-limiting performance, the SC-6 safeguards sensitive electronics without unnecessary voltage drops. This fuse also offers straightforward replacement in standard Bussmann circuits and aligns with Eaton’s proven Bussmann series technology, delivering predictable protection, reduced downtime, and simplified compliance across diverse automation environments.
Product Information
Extended Description
SC-6 Eaton: Eaton Bussmann Series Class G fuse, SC, fast-acting, current limiting fuse, 6 A, rejection style fuse, interrupting rating of 100 kA at 600 Vac and 10 kA at 170 Vdc
Product Name
Eaton Bussmann series SC fuse
Catalog Number
SC-6
UPC
051712250061
Product Length/Depth
1.31 in
Product Height
0.41 in
Product Width
0.41 in
Product Weight
0.1 lb
Warranty
Not Applicable
Compliances
RoHS Compliant
Amperage Rating
6 A
Interrupt rating
100 kAIC at 600 Vac 10 kAIC at 170 Vdc
Voltage rating
600 Vac, 170 Vdc
Packaging type
Standard
Class
Class G
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Special features
Rejection style
Low Voltage Branch Circuit Fuse Chapter
Low Voltage Branch Circuit Fuse Chapter
RoHS Search Tool
Bussmann series Fuseology
Bussmann series Rejecting Fuses data sheet no. 1024
The fast-acting, current-limiting design delivers rapid fault interruption, reducing downstream damage and improving overall system uptime. Business impact: minimized downtime and safer startup sequences in automation cabinets; application: protection of control circuits in conveyors, pumps, and motor drives. The rejection-style mechanism prevents incorrect fuse installation in fuse blocks, reducing field errors and warranty claims; application: panel assemblies with limited clearance and mixed fuse types. Ferrule-end connections ( ferrule end x ferrule end ) ensure secure, vibration-resistant terminations; business impact: reliable maintenance and quicker replacements in harsh environments; application: standard Bussmann blocks and compact enclosures. The Class G rating and 6 A nominal rating deliver precise protection without nuisance trips; business impact: stable control logic and predictable trip curves; application: low- to mid-current control circuits in automation. RoHS compliance and standard packaging streamline sourcing, inventory, and regulatory alignment; application: mixed-fleet deployments across global facilities. The 1.31 in length and 0.41 in width/height enable easy integration into compact panels; business impact: space-efficient protection with universal compatibility; application: retrofit projects and new builds alike.
Get a Quick Quote for a Eaton SC-6
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton SC-6?
Enquire Now
FAQs
SC-6 is a Class G, current-limiting fuse with ferrule end connections designed for Bussmann series panels. It fits standard fuse blocks and controls up to 6 A with a 1.31 in length, enabling straightforward swapping in existing control cabinets and instrumentation enclosures. Its rejection style helps ensure correct installation in compatible holders.
The SC-6 fuse is rated for 6 A with a voltage rating of 600 Vac and 170 Vdc. It provides an interrupt rating of 100 kAIC at 600 Vac and 10 kAIC at 170 Vdc, offering robust protection for motor drives, sensors, and control circuits without excessive voltage drop or premature tripping in normal operation.
Yes, the SC-6 fuse is RoHS compliant, meaning it meets environmental and safety standards restricting hazardous substances in electrical components. This helps streamline regulatory approvals and packaging waste considerations in electronics assemblies, supports sustainable manufacturing practices, and simplifies procurement for global facilities.
Best suited for protection of control panels, automation equipment, and low-to-mid-current circuits in industrial environments. Its fast-acting design minimizes damage from short circuits, while the current-limiting feature reduces fault energy. Applications include conveyors, pumps, machine controllers, and power distribution blocks in automation and process industries.
Plan for ferrule-end x ferrule-end connections and a compact footprint (1.31 in length, 0.41 in width/height). Use standard packaging and mounting in compatible Bussmann blocks. The rejection-style design helps prevent misinsertion, improving reliability in panel assemblies. Ensure the panel space accommodates 600 Vac circuits and the device’s current rating to avoid nuisance trips.
