Eaton SCB2034B120480C6 Pringle Pressure Switch UL Listed
Part Number: SCB2034B120480C6
Quick Summary
Eaton SCB2034B120480C6 pressure switch is designed to deliver reliable pressure sensing and control for high-current electrical systems in industrial facilities. Operators struggle with maintaining accurate, safe operation when wiring large feeders into crowded panels, especially at 480 V and 2000 A. UL Listed certification underscores compliance with essential electrical safety standards for electrical equipment in critical infrastructure. The three-pole, three-wire bottom-feed design plus a sturdy 6 ft 6 in handle simplifies installation and enhances reliability in demanding environments, supporting reduced downtime and easier maintenance. This solution aligns with heavy-power control needs while integrating with standard Eaton switchgear, delivering improved reliability and total cost of ownership.
Product Information
Extended Description
SCB2034B120480C6 Eaton: Pringle(Special)BPS, 2000A, Bottom, 480V 3P w/N-CT, ArcRed/GF Relay-CT, 6'6" hndl
Product Name
Eaton pringle bolted pressure contact switch
Catalog Number
SCB2034B120480C6
UPC
786689773434
Product Length/Depth
16 in
Product Height
28 in
Product Width
24 in
Product Weight
180 lb
Certifications
UL Listed
Feed type
Bottom
Fuse configuration
Bottom feed
Number Of Poles
Three-pole
Number of wires
Three-wire
Amperage Rating
2000A
Voltage rating
480 V
Feature: 2000A amperage rating at 480V with a three-pole bolted pressure contact switch. Business Impact: Enables direct switching of large three-phase loads, reducing device count and simplifying protection coordination across switchgear. Application: Ideal for motor control centers and heavy-power feeders in industrial facilities.Feature: Bottom-feed fuse configuration and bottom-feed wiring design. Business Impact: Streamlines installation, minimizes enclosure depth, reduces wiring complexity. Application: Suitable for new panel installations and retrofit projects in space-constrained environments.Feature: UL Listed certification validating electrical safety and adherence to recognized standards. Business Impact: Facilitates regulatory compliance, supports audits, and increases operator confidence in safety-critical processes. Application: Plant-wide safety programs and customer inspections in North America and similar markets.Feature: Three-pole, three-wire architecture with arc-management features referenced as ArcRed/GF Relay-CT. Business Impact: Extends contact life under high-energy switching, reduces arcing risk, improves maintenance intervals. Application: Power distribution and motor-control applications in harsh environments.Feature: Robust dimensions and weight — 16 in length, 28 in height, 24 in width, 180 lb — enabling solid mounting and predictable enclosure planning. Business Impact: Improves mounting stability and simplifies space calculations, reducing misfits and rework. Application: Floor-standing or heavy-duty panel installations in large switchgear enclosures.
Get a Quick Quote for a Eaton SCB2034B120480C6
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton SCB2034B120480C6?
Enquire Now
FAQs
Begin by selecting a suitable enclosure with adequate clearance for a three-pole, bottom-feed device and the 180 lb weight. Align the switch mounting to the panel frame, connect bottom-feed conductors to the appropriate terminals with proper torque per manufacturer guidelines, and route wiring to minimize exposure. Confirm the 480 V rating and test the integrity of the arc-safety features before commissioning.
Yes. The SCB2034B120480C6 is specified with a bottom-feed configuration and fuse wiring approach suitable for bottom-feed panels. When integrating, ensure enclosure space accommodates the 16 in length, 28 in height, and 24 in width, and verify that wiring routes meet the bottom-feed layout to maintain safe clearances and ease maintenance.
This three-pole, three-wire switch is ideal for high-current distribution and motor control in industrial automation—such as motor control centers, switchgear assemblies, and heavy-power distribution panels. Its 2000A at 480V rating supports direct switching of large three-phase loads, reducing device count and simplifying protection schemes in demanding environments.
UL Listed indicates the device meets recognized safety standards for electrical equipment, supporting safer operation and regulatory compliance. For installations, maintain the UL documentation, follow wiring and mounting guidelines, ensure compatible enclosures, and verify any regional requirements such as CE marking or local electrical codes where applicable.
The 2000A, 480V rating combined with a robust bolted contact design and ArcRed/GF features reduces arcing wear and the need for frequent replacements. Anticipate lower downtime, fewer spare parts, and longer intervals between maintenance cycles, delivering a favorable total cost of ownership in high-energy panel applications.
