Eaton SHUNT BRD 110-120VAC - Anti-pump Relay IEC Rated
Part Number: SHUNT BRD 110-120VAC
Manufacturer
Eaton
Part number
SHUNT BRD 110-120VAC
Quick Summary
Eaton SHUNT BRD 110-120VAC is a shunt board that provides anti-pump protection for W-VAC motor controls. This solution addresses nuisance pumping and unwanted tripping that can lead to downtime and accelerated wear on critical equipment. It features IEC Rated construction for reliable operation in industrial environments, aligning with global safety standards. Designed for straightforward integration, the unit’s 8 in by 6 in by 3 in footprint and 3 lb weight simplify mounting in control panels, while the 110-120 V rating matches common field wiring. For procurement and maintenance teams, this kit offers predictable performance and a clear warranty path, helping minimize service interruptions and inventory complexity.
Product Information
Extended Description
SHUNT BRD 110-120VAC Eaton: Eaton shunt board assembly kit, 110-120 Vac, Used with W-VACiMB
Product Name
Eaton W-VAC anti-pump relay
Catalog Number
SHUNT BRD 110-120VAC
UPC
786685632537
Product Length/Depth
8 in
Product Height
3 in
Product Width
6 in
Product Weight
3 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
IEC Rated
Used with
W-VACiMB
Type
Anti-pump relay
Voltage rating
110-120 V
Feature: Anti-pump relay integrated into a compact shunt board. Business Impact: Reduces nuisance pump cycling and associated wear, improving pump longevity and system uptime. Application: Ideal for W-VAC motor control circuits in HVAC and process environments. Feature: 110-120 V voltage rating. Business Impact: Enables straightforward integration with common control panel power rails, reducing wiring errors and installation time. Application: Fits standard industrial panels in HVAC, water treatment, and processing plants. Feature: Physical footprint of 8 in L × 6 in W × 3 in H and weight of 3 lb. Business Impact: Small form factor facilitates dense panel layouts and lighter handling during installation, lowering labor costs. Application: Suitable for crowded control enclosures in OEM builds and retrofit projects. Feature: IEC Rated certification and W-VACiMB compatibility. Business Impact: Supports regulatory compliance and proven interoperability within Eaton’s W-VAC ecosystem, reducing integration risk. Application: OEM and maintenance teams gain faster commissioning and easier support. Feature: Catalog number SHUNT BRD 110-120VAC with 1-year to 18-month warranty window. Business Impact: Clear sourcing and risk mitigation for service life, minimizing unexpected replacement costs. Application: Procurement-ready for stocking in parts rooms and service inventories.
Get a Quick Quote for a Eaton SHUNT BRD 110-120VAC
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton SHUNT BRD 110-120VAC?
Enquire Now
FAQs
The SHUNT BRD 110-120VAC is designed to work with Eaton's W-VACiMB module, fitting standard 110-120 VAC control panels. It simplifies wiring and protects against pump re-starts, enabling quick, reliable integration in HVAC and process-control applications. Follow the provided Eaton specification sheet for mounting, wiring diagrams, and compatibility notes to ensure proper installation.
The assembly measures 8 inches in length, 6 inches in width, and 3 inches in height, with a weight of 3 pounds. This compact footprint supports dense panel layouts, reduces enclosure footprint, and speeds up installation by allowing easier handling and mounting within crowded electrical cabinets.
Key specs include a voltage rating of 110-120 V and an anti-pump relay function. The device is used with W-VACiMB for motor control and is well-suited for HVAC controllers and process equipment where nuisance pump cycling can cause downtime and wear. This combination delivers improved reliability in critical pumping applications.
The product is IEC Rated, indicating compliance with international safety and performance standards. This helps streamline global procurement and reduces risk in regulated environments. Ensure your panel documentation references the IEC-rated protection when evaluating electrical protection components.
The warranty follows Eaton policy 25-000, offering one year from the date of installation or eighteen months from the date of shipment, whichever occurs first. This provides a clear risk-management window for maintenance planning and supports cost-of-ownership considerations in equipment fleets.
