Eaton SHUNT BRD 220-250VDC Shunt Board - IEC Rated
Part Number: SHUNT BRD 220-250VDC
Manufacturer
Eaton
Part number
SHUNT BRD 220-250VDC
Quick Summary
SHUNT BRD 220-250VDC shunt board is a compact anti-pump relay kit for Eaton W-VAC protection schemes. Engineers face nuisance pump faults and downtime in DC motor control; this assembly helps prevent unplanned outages by reliably interrupting backfeed. Certified IEC Rated, it aligns with global electrical protection standards and supports best practices in OEM and panel builder projects. With a small 8 by 6 by 3 inch footprint and a 3 lb weight, installation in control panels is straightforward and serviceable. Leveraging a dedicated W-VACiMB interface, the SHUNT BRD reduces wiring complexity and maintenance costs, delivering faster time-to-operation and lower total cost of ownership.
Product Information
Extended Description
SHUNT BRD 220-250VDC Eaton: Eaton shunt board assembly kit, 220-250 Vdc, Used with W-VACiMB
Product Name
Eaton W-VAC anti-pump relay
Catalog Number
SHUNT BRD 220-250VDC
UPC
786685632520
Product Length/Depth
8 in
Product Height
3 in
Product Width
6 in
Product Weight
3 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
IEC Rated
Used with
W-VACiMB
Type
Anti-pump relay
Voltage rating
220 - 250 V DC
Compact, panel-friendly design supports rapid deployment and scalable protection in crowded control panels. The 8 in x 6 in x 3 in footprint and 3 lb weight minimize enclosure footprint while preserving serviceability, which translates to faster installation and easier future maintenance. This is ideal for Eaton W-VACiMB systems in mixed-Voltage DC applications. Voltage rating of 220-250 VDC ensures compatibility with common DC pump circuits and reduces wiring error risk. IEC-rated protection provides confidence in compliance with industrial standards, minimizing qualification time for APQP processes. Used with W-VACiMB, the SHUNT BRD simplifies wiring and interconnection, enabling quicker panel commissioning and easier field servicing. The Catalog Number SHUNT BRD 220-250VDC and the 220-250 VDC rating support straightforward procurement and reduction of stock variety. Warranty terms, Eaton support, and a robust mechanical design help lower total cost of ownership over the product life. Built to operate in protection schemes that require anti-pump behavior, this shunt board delivers predictable performance in busy automation environments.
Get a Quick Quote for a Eaton SHUNT BRD 220-250VDC
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton SHUNT BRD 220-250VDC?
Enquire Now
FAQs
The SHUNT BRD 220-250VDC is designed for use with Eaton W-VAC protection schemes and specifically pairs with the W-VACiMB interface. Its footprint (8 in x 6 in x 3 in) and weight (3 lb) facilitate straightforward panel mounting and future serviceability. Ensure mounting clearances within the control panel and verify electrical connections follow the W-VACiMB wiring diagram for reliable anti-pump operation.
Key specifications include a voltage rating of 220–250 V DC, catalog number SHUNT BRD 220-250VDC, dimensions of 8 in length, 6 in width, 3 in height, and a weight of 3 lb. The device is IEC Rated, used with W-VACiMB, and supports an anti-pump relay function within DC motor protection circuits.
Yes. The SHUNT BRD 220-250VDC provides an anti-pump relay function designed to interrupt pump backfeed, reducing nuisance trips and unplanned downtime. It is intended for integration with Eaton W-VAC protection schemes and the W-VACiMB interface to deliver reliable DC motor protection in industrial environments.
The product is IEC Rated, indicating conformity with IEC-based electrical protection standards. This certification supports compliance during system integration, OEM qualification, and panel-building audits, helping to streamline acceptance tests and supplier qualification processes.
Warranty terms follow Eaton Selling Policy 25-000: one year from the date of installation or eighteen months from the date of shipment, whichever occurs first. This provides protection against manufacturing defects while aligning with common industrial procurement expectations.
