Eaton SMS4PDH1 Connector - Push-Pull Plastic IP30
Part Number: SMS4PDH1
Quick Summary
The Eaton SMS4PDH1 connector provides quick mating for reliable panel wiring in industrial machines. Engineers often contend with stubborn terminations, loose connections, and costly downtime; this design minimizes mis-matches and speeds field servicing. It aligns with RoHS and REACH environmental standards, uses UL94 V0 plastics for fire safety, and offers IP30 protection for general industrial use. Compatible with Souriau SMS series harnesses and includes integrated strain relief, enabling compact, rugged installations that lower rework and warranty risk. For procurement teams, the 4-contact, push-pull design simplifies stocking and maintenance planning.
Product Information
Extended Description
SMS4PDH1 Eaton: Cable plug with integrated strain relief; SMS4PDH1
Product Name
Eaton Souriau SMS series quick mating plastic rectangular connector
Catalog Number
SMS4PDH1
Product Length/Depth
57.1 mm
Product Height
16.4 mm
Product Width
23.7 mm
Product Weight
5.8 g
Environmental conditions
RoHS Flammability rating UL94 V0 REACH
Backshell type
Strain Relief
Connector accessory option
Integrated with connector
Connector type
Plug
Contact delivery
Not delivered
Contact type
Crimp
Coupling type
Push-Pull
Degree of protection
IP30
Layout
4
Plug type
Straight Plug
Shell material
Plastic
Operating temperature - max
125 °C
Operating temperature - min
-55 °C
Number Of Contacts
4
Number of cavity #16
4
Feature: Push-Pull quick mating reduces assembly time. Benefit: Speeds commissioning, lowers labor costs, and improves first-time quality in control cabinets and machine wiring. Application: Ideal for automation panels and robotic systems where cycle time matters. Feature: Integrated strain relief backshell. Benefit: Protects against cable stress, extends connector life, and reduces field failures. Application: Harnesses on heavy machinery and conveyor systems where vibrations are common. Feature: 4-position, 4-crimp contact layout. Benefit: Predictable interconnects with straightforward crimping processes, enabling repeatable performance. Application: Multi-signal or power-and-signal bundles in industrial automation.Feature: Plastic shell with RoHS/REACH compliance and UL94 V0 rating. Benefit: Safer material in fire-prone environments and compliant supply chains. Application: General industrial automation and process control where regulatory adherence is essential.Feature: Compact footprint and short mating depth (57.1 mm L x 23.7 mm W x 16.4 mm H; 5.8 g). Benefit: Saves panel space and supports dense wiring layouts. Application: Small to mid-size control panels and tight equipment enclosures.Feature: IP30 protection with 4 cavities and straight plug configuration. Benefit: Suitable for unsealed indoor applications with robust daily use. Application: Control cabinets, machinery interfaces, and automation modules requiring reliable connections.
