Eaton SPECIAL605 Complete Molded Case Circuit Breaker - IEC

Part Number: SPECIAL605
SPECIAL605
Manufacturer
Eaton
Part number
SPECIAL605
Category

Quick Summary

The Eaton SPECIAL605 is a complete molded case circuit breaker designed to protect and control power in industrial distribution panels. Engineers often wrestle with matching trip characteristics, line-side wiring, and compatibility across voltage ranges, delaying panel commissioning. This model is IEC Rated and offers an 80 A rating, 690 V AC operation, and a 100 kAIC interrupt rating in a J-frame, three-pole package. With remote shunt-trip and auxiliary options, SPECIAL605 supports reliable protection, faster maintenance, and simplified procurement for industrial power distribution. Designed for modular panel designs and feed-through connections, it enables easier installation, consistent performance, and compliant operation in harsh plant environments.

Product Information

Extended Description

SPECIAL605 Eaton: Eaton Series C complete molded case circuit breaker, J-frame, FWC, Adj. thermal, fixed magnetic trip, Three-pole, 80A, 690 Vac, 100 kAIC at 415 Vac, 48-127 Vac or 48-60 Vdc rear w/ 36 in left pigtail, 400 Hz, Feed-thru
Product Name
Eaton Series C complete molded case circuit breaker
Catalog Number
SPECIAL605
UPC
782116109524
Product Length/Depth
4.06 in
Product Height
4.13 in
Product Width
4.13 in
Product Weight
0.01 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
IEC Rated
Type
Complete breaker
Amperage Rating
80 A
Voltage rating
690 V AC
Trip Type
Adjustable thermal, fixed magnetic
Circuit breaker type
FWC
Circuit breaker frame type
Complete breaker
Auxiliary switch
1A-1B rear with 36 in right pigtail
Shunt trip
48-127 Vac or 48-60 Vdc left pigtail rear with 36 in leads
Frame
J
Calibration
400 Hz
Interrupt rating
100 kAIC at 415 Vac
Connection
Feed-through
Number of poles
Three-pole
Application of Multi-Wire Terminals for Molded Case Circuit Breakers Application of Multi-Wire Terminals for Molded Case Circuit Breakers Application of Multi-Wire Terminals for Molded Case Circuit Breakers Plug-in adapters for molded case circuit breakers product aid Plug-in adapters for molded case circuit breakers product aid Plug-in adapters for molded case circuit breakers product aid Plug-in adapters for molded case circuit breakers product aid Plug-in adapters for molded case circuit breakers product aid Plug-in adapters for molded case circuit breakers product aid Plug-in adapters for molded case circuit breakers product aid Breaker service centers Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2 Circuit breakers explained Circuit breakers explained MOEM MCCB product selection guide MOEM MCCB product selection guide MOEM MCCB product selection guide MOEM MCCB product selection guide MOEM MCCB product selection guide Selling Policy 25-000 - Distribution and Control Products and Services
Feature: 80 A amperage rating in a three-pole J-frame design. Business impact: provides precise protection for standard industrial loads while minimizing nuisance trips, enabling predictable maintenance cycles. Application: motor control centers and distribution panels with typical 80 A demand. Feature: 690 V AC operating voltage with a 100 kAIC interrupt rating at 415 Vac. Business impact: supports high fault-current environments and rapid fault clearance, reducing damage and downtime. Application: large motors, conveyors, and processing lines in medium- to high-voltage plants. Feature: Trip type is adjustable thermal with a fixed magnetic element. Business impact: lets you tailor the protective curve to load characteristics, improving selectivity and system reliability. Application: varied industrial loads where overload and short-circuit protection must be precisely balanced. Feature: FWC circuit breaker type with a complete breaker frame and three poles. Business impact: ensures compatibility with standard Series-C MCCB assemblies and simplifies panel installation. Application: main protection in 3-phase distribution schemes. Feature: Remote accessory readiness including 1A-1B rear auxiliary switch and 48-127 Vac or 48-60 Vdc shunt-trip with 36 in leads. Business impact: enables remote signaling and trip interlock capabilities, improving safety and control integration. Application: centralized protection schemes and automated shutdown sequences. Feature: Feed-through connection and compact dimensions (4.06 in L x 4.13 in W x 4.13 in H) with light weight (~0.01 lb). Business impact: simplifies wiring and reduces panel footprint, enabling higher density installations. Application: space-constrained panels and retrofit projects. Feature: IEC Rated certification and documented compatibility with industry MCCB standards. Business impact: supports global procurement and compliance programs, reducing audit findings. Application: multinational deployments and cross-site maintenance.
