Eaton T100M Condulet Form 5 conduit outlet body - NEC/CEC
Part Number: T100M
Quick Summary
The Eaton T100M Condulet Form 5 conduit outlet body provides rugged 1-inch conduit terminations for form 5 enclosures in industrial facilities. Engineers often struggle with fittings that don’t fit standard conduits or withstand ordinary environments, leading to costly field adjustments and downtime. It is NEC/CEC compliant and UL-listed for ordinary/non-hazardous locations, with Canada-specific certifications available. Designed for durable metal conduit systems, this Form 5, 1" trade-size body offers reliable performance in control panels, switchgear, and process equipment, reducing maintenance and installation time. By aligning with Eaton’s Condulet Form 5 ecosystem, it enables faster procurement and predictable field results across multi-site operations, while simplifying regulatory compliance and installation planning for industrial environments.
Product Information
Extended Description
T100M Eaton: Eaton Crouse-Hinds series Condulet Form 5 conduit outlet body, Malleable iron, T shape, 1"
Product Name
Eaton Crouse-Hinds series Condulet Form 5 conduit outlet body
Catalog Number
T100M
UPC
782274756257
Product Length/Depth
7.05 in
Product Height
2.65 in
Product Width
1.8 in
Product Weight
1.96 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Shape
T
Trade size
1"
Material
Malleable iron
Eaton Crouse-Hinds T100M 3D drawing
Crouse-Hinds series Form 5 catalog page
Condulet Form 5 Conduit Outlet Bodies UL certification
Condulet Form 5 Conduit Outlet Bodies UL certification
Eaton Specification Sheet - T100M
Feature: Malleable iron Form 5 conduit outlet body in a T shape. Business impact: provides robust mechanical strength and vibration resistance, reducing field failures in heavy-duty installations. Application: panel wiring and machine housing where form 5 fittings are standard. Feature: 1-inch trade size with 7.05 inch length, 2.65 inch height, and 1.8 inch width; weight 1.96 lb. Business impact: easier handling and accurate fitment in tight control panels, accelerating assembly. Application: compact enclosures and overhead installations needing precise form 5 termination. Feature: NEC/CEC compliant and area classification Ordinary/Non-Hazardous Locations. Business impact: streamlines compliance, audit readiness, and reduces regulatory risk. Application: manufacturing floors and process facilities with standard electrical rooms. Feature: compatibility with the Eaton Condulet Form 5 family and quick mounting. Business impact: faster procurement cycles and lower total installed cost. Application: multi-product installations across sites where standardization matters. Feature: UL listings and downloadable resources (catalog page, 3D CAD drawing, specification sheet). Business impact: improves design accuracy and reduces rework during engineering reviews. Application: pre-fab assemblies and system designs relying on verified references.
