Eaton T25 Condulet Series 5 Outlet Body - NEC/CEC
Part Number: T25
Quick Summary
The Eaton T25 Condulet Series 5 conduit outlet body provides rugged terminations for rigid/IMC conduits in industrial panels. Unsecured terminations can suffer corrosion, misalignment, or sealing issues that drive downtime. It aligns with NEC/CEC standards and is rated for Ordinary/Non-Hazardous Locations, with UL certifications documented. This solution delivers reliable, compliant terminations in controlled environments, helping minimize field rework and downtime. By leveraging copper-free aluminum construction and a compact 3/4" trade size, it also supports streamlined procurement and installation, reducing total cost of ownership while maintaining safety and performance in wiring & connectivity applications.
Product Information
Extended Description
T25 Eaton: Eaton Crouse-Hinds series Condulet Series 5 conduit outlet body, Rigid/IMC, Copper-free aluminum, T shape, 3/4"
Product Name
Eaton Crouse-Hinds series Condulet Series 5 conduit outlet body
Catalog Number
T25
UPC
784564140425
Product Length/Depth
5.4 in
Product Height
1.64 in
Product Width
1.53 in
Product Weight
0.4 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Shape
T
Conduit type
Rigid/IMC
Trade size
3/4"
Material
Copper-free aluminum
Crouse-Hinds series Series 5 brochure
Crouse-Hinds series Series 5 catalog page
Condulet Series 5 Conduit Outlet Bodies UL certification
Condulet Series 5 Conduit Outlet Bodies UL certification
Eaton Specification Sheet - T25
Feature → Business Impact → Application: Copper-free aluminum construction delivers corrosion resistance with reduced weight, improving handling during installation and lowering labor fatigue on large panel builds. This translates to faster onboarding of Condulet Series 5 components and lower maintenance costs in high-density panels used in automation systems. Application: Ideal for 3/4" rigid/IMC terminations in control cabinets and equipment enclosures where weight savings and long-term durability matter. Feature → Business Impact → Application: T-shaped, Series 5 conduit body design provides predictable alignment and consistent gasket seating, reducing commissioning time and rework. Application: Suitable for ordinary/non-hazardous locations in machine centers and process lines, where quick, reliable terminations are essential. Feature → Business Impact → Application: 5.4 in length, 1.64 in height, 1.53 in width, and 0.4 lb weight enable compact layouts in tight spaces and enable easier stocking within standard wiring & connectivity kits. Application: Panel builders and integrators benefit from predictable fit within Eaton Condulet ecosystems, simplifying procurement and installation. Feature → Business Impact → Application: NEC/CEC compliance and UL certification support regulatory acceptance and audits, lowering risk during customer qualification and site inspections. Application: Use in controlled environments to meet electrical code requirements without sacrificing ease of installation. Feature → Business Impact → Application: Rigid/IMC compatibility ensures robust mechanical protection of terminations, reducing field damage and rework in harsh factory settings. Application: Industrial automation panels, machine enclosures, and junction box terminations where reliability and fast install are paramount.
Get a Quick Quote for a Eaton T25
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton T25?
Enquire Now
FAQs
The T25 supports a 3/4" trade size and is designed for use with rigid/IMC conduits, pairing with Eaton Condulet Series 5 accessories. It enables proper alignment and secure termination within panels or enclosures, reducing misalignment risks and field rework during installation in standard industrial settings.
Key specs include a 3/4" trade size, T-shaped body, copper-free aluminum construction, 5.4 in length, 1.64 in height, 1.53 in width, and a weight of 0.4 lb. UPC is 784564140425 and catalog number T25, making it straightforward to locate in the Condulet Series 5 family.
Yes. The T25 conforms to NEC/CEC standards and is specified for Ordinary/Non-Hazardous Locations. UL certification is documented in Eaton’s product literature, ensuring regulatory acceptance and streamlined audits in industrial environments.
Copper-free aluminum reduces weight and eliminates copper-related galvanic issues, improving handling and reducing labor costs during installation. The material also offers good corrosion resistance, extending service life in non-hazardous environments and contributing to lower maintenance expenses over the panel’s lifecycle.
The T25 delivers faster, easier installations with reliable terminations, reducing commissioning time and field rework. Its NEC/CEC compliance and UL documentation reduce audit risk. Combined with lightweight materials and Series 5 compatibility, it lowers total cost of ownership while improving panel reliability in industrial wiring and connectivity applications.
