Eaton T30060-2SR Class T modular fuse block - 200 kAIC
Part Number: T30060-2SR
Quick Summary
The Eaton Class T modular fuse block T30060-2SR delivers reliable 31–60 A circuit protection for control panels. Engineers commonly face space constraints, wiring errors, and inconsistent interrupt performance across assemblies. This model is RoHS compliant and UL Recognized, CSA Certified, providing clear regulatory footing for electrical installations in industrial environments. Designed for easy screw connections with #18-10 AWG copper conductors, it accelerates installation, minimizes field wiring mistakes, and supports robust short-circuit response. With a two-pole Class T design rated at 200 kAIC and 300 V, it offers scalable protection that aligns with modern safety standards while reducing total cost of ownership through durable, code-compliant performance.
Product Information
Extended Description
T30060-2SR Eaton: Eaton Bussmann series Class T modular fuse block, 31-60 A, Two-pole, Class T, Screw, 200 kAIC, 300 Vac/dc, #18-10 AWG Cu
Product Name
Eaton Bussmann series Class T modular fuse block
Catalog Number
T30060-2SR
UPC
051712149792
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.35 lb
Warranty
Not Applicable
Compliances
RoHS Compliant
Certifications
Contact Manufacturer UL Recognized CSA Certified
Amperage Rating
31-60A
Interrupt rating
200 kAIC
Short-circuit rating
200 kA
Voltage rating
300 Vac/dc
Number of Poles
Two-pole
Wire size
#18-10 AWG Cu
Class
Class T
Connection
Screw
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - T30060-2SR
Feature: Two-pole Class T modular fuse block with screw terminals enables compact, secure wiring in dense panels. Business impact: Reduces wiring errors, accelerates installation, and improves fault isolation for faster maintenance. Application: Suited for control panels, machine controllers, and motor starter circuits in modern automation environments. Feature: 200 kAIC interrupt rating and 200 kA short-circuit rating at 300 Vac/dc deliver robust protection for high-energy faults. Business impact: Improves safety margins and regulatory compliance while helping your panels withstand surges without component damage. Application: Industrial switchgear and panel boards in manufacturing and process facilities. Feature: Wire compatibility with #18-10 AWG Cu simplifies field wiring and spares stocking. Business impact: Reduces inventory complexity and enables quick field changes, lowering downtime. Application: General purpose protective circuits in compact control panels. Feature: RoHS compliant with UL Recognized and CSA Certified markings. Business impact: Streamlines procurement and compliance audits, reducing risk and certification costs. Application: Worldwide deployments across automotive, packaging, and food & beverage equipment where regulatory adherence matters. Feature: Access to Eaton Bussmann series documentation and catalogs for quick reference. Business impact: Improves parts correlation, speeds design reviews, and supports compliant installs. Application: Engineers sourcing fuses for control panels and panel boards.
Get a Quick Quote for a Eaton T30060-2SR
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton T30060-2SR?
Enquire Now
FAQs
The T30060-2SR is a two-pole Class T modular fuse block designed to protect control-panel circuits in the 31–60 A range. It uses screw terminals for reliable, space-efficient wiring and supports high-energy fault protection, making it suitable for machine controllers and motor starter assemblies in industrial environments.
Yes. The T30060-2SR is rated for 300 Vac/dc, enabling use in both AC and DC control circuits. Its 200 kAIC interrupt rating provides robust protection against high-energy faults, which is critical for DC systems where arcing can be a concern.
The fuse block accepts #18-10 AWG copper conductors, offering flexibility for common control-wiring standards. This compatibility simplifies sourcing, reduces stocking variety, and supports straightforward field installation in compact panels.
The T30060-2SR carries RoHS compliance, UL Recognized, and CSA Certified markings. These certifications help ensure regulatory compliance, simplify audits, and support global deployment in regulated industries such as manufacturing and automotive equipment.
With a two-pole Class T design, screw-terminal connection, and a high interrupt rating, this fuse block provides fast fault isolation and reliable protection. The combination reduces troubleshooting time, minimizes unplanned outages, and supports predictable maintenance planning for production lines.
