Eaton TB200-18 Panel Mount Terminal Block - 18-Pole CE RoHS
Part Number: TB200-18
Quick Summary
TB200-18 panel mount terminal block is a rugged connector solution for organizing 18 circuits in electrical control panels. Manufacturers often wrestle with space constraints, signal integrity, and safe isolation in limited panel real estate. This unit carries CE marking and RoHS compliance, with barrier terminals and robust tin-plated brass contacts to support reliable operation in demanding environments. Designed for panel wiring and connectivity efficiency, TB200-18 helps reduce wiring time, improve traceability, and simplify maintenance in control cabinets. Its compact footprint and 18-pole capacity make it ideal for high-density automation layouts, while standard 6-32 TPI screws ensure straightforward installation and dependable long-term performance. This translates to reduced panel downtime and lower total cost of ownership.
Product Information
Extended Description
TB200-18 Eaton: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800 V, 300 V, 30 A, Barrier, 18-pole, 6-32 TPI Screw, Black, Tin-plated brass terminal, Zinc-plated steel philslot screw
Product Name
Eaton Bussmann TB200 series panel mount terminal block connector
Catalog Number
TB200-18
UPC
051712272155
Product Length/Depth
8.62 in
Product Height
0.56 in
Product Width
1.12 in
Product Weight
3.6 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
Contact Manufacturer
Amperage Rating
30A
Voltage rating
300 V
Number Of Poles
18-pole
Type
Double row, barrier
The 18-pole, double-row barrier design delivers clear circuit segregation and a compact footprint. This configuration improves wiring clarity, reduces mis-termination risk, and speeds panel assembly, making it ideal for dense control panels in automation systems. The 6-32 TPI screw terminals provide secure, vibration-resistant terminations that minimize field rework and re-termination costs, supporting reliable connections for motor drives and PLC I/O. With 30A at 300V and an 4800V breakdown voltage, TB200-18 offers ample insulation margin for power distribution despite crowded installations, enhancing safety and performance in standard industrial environments. Tin-plated brass terminals and zinc-plated steel philslot screws deliver corrosion resistance and durable operation under harsh conditions. The panel-mount design and a profile of 8.62 in length, 1.12 in width, and 0.56 in height simplify retrofit and new-build installations, reducing enclosure footprint and simplifying inventory management. Compliance with CE and RoHS further ensures regulatory alignment across European and global sites, enabling streamlined procurement and consistent quality across projects.
Get a Quick Quote for a Eaton TB200-18
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton TB200-18?
Enquire Now
FAQs
TB200-18 uses standard 6-32 TPI screws, a common size for power and control wiring in industrial panels. This compatibility means quick terminations, straightforward field maintenance, and reduced need for special tools or adapters during installation.
TB200-18 is rated for 30A at 300V with a breakdown voltage of 4800V. These specifications provide a robust insulation margin for typical control-panel circuits, supporting reliable operation under normal and transient conditions while maintaining safe isolation between poles.
Yes. The 18-pole, double-row barrier design delivers dense, organized wiring with clear isolation. Its compact footprint reduces panel depth, improves traceability, and simplifies future rework in high-density automation layouts.
TB200-18 is CE marked and RoHS compliant, indicating adherence to European safety and material standards. These certifications support regulatory compliance, supplier reliability, and smoother cross-border procurement for international projects.
With a panel-mount design and standard screw-terminals, TB200-18 enables fast, tool-accessible terminations and straightforward reinforcement or re-termination. The barrier design reduces wiring errors, while its measured depth and width fit common enclosures, accelerating retrofit or expansion projects.
