Eaton TB200-18P Panel Mount Terminal Block - 18-pole
Part Number: TB200-18P
Quick Summary
The Eaton TB200-18P panel mount terminal block provides barrier-style 18-pole connections for compact panel wiring. Design engineers often struggle with reliable high-voltage terminations in tight panel layouts. This TB200-18P is CE marked and RoHS compliant, supporting 4800 V breakdown, 300 V working voltage, and a 30 A rating. These certifications and electrical ratings help ensure safety, environmental compliance, and long-term reliability in industrial control panels. With compact footprint and strong compatibility with standard wiring practices, it reduces panel space and installation time. Engineers will value clear labeling, barrier separation, and easy maintenance when diagnosing circuit terminations. Overall, TB200-18P supports scalable wiring in automation and power distribution applications.
Product Information
Extended Description
TB200-18P Eaton: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800 V, 300 V, 30 A, Barrier, 18-pole, 6-32 TPI Screw, Black, Tin-plated brass terminal, P-style Steel SEMS philslot screw
Product Name
Eaton Bussmann TB200 series panel mount terminal block connector
Catalog Number
TB200-18P
UPC
051712194327
Product Length/Depth
8.62 in
Product Height
0.56 in
Product Width
1.12 in
Product Weight
3.6 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
Contact Manufacturer
Amperage Rating
30A
Voltage rating
300 V
Number Of Poles
18-pole
Type
Double row, barrier
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Feature: High-density 18-pole barrier design enables compact panel wiring. Business Impact: This arrangement delivers 18 independent terminations in a dual-row configuration, maximizing space efficiency on crowded control panels and reducing backplane crowding. Application: Ideal for machine dashboards and power distribution within industrial automation panels where space is at a premium. Feature: 30 A at 300 V with 4800 V breakdown. Business Impact: The voltage and current ratings support safe, reliable operation for motor starters and control circuits, while the high breakdown voltage provides added insulation margin during switching transients. Application: Useful for panel feeders, distributed I/O, and high-load control circuits in manufacturing lines. Feature: Robust materials and hardware. Business Impact: Tin-plated brass terminals and P-style SEMS screws with 6-32 TPI provide corrosion resistance and secure terminations, reducing maintenance and rework. Application: Suitable for environments with moisture exposure or where long service life is required; easy field re-termination when wiring changes. Feature: Panel mount, dual-row configuration. Business Impact: Panel mounting simplifies enclosure routing and eliminates need for separate DIN rails, offering straightforward integration with existing assemblies. Application: Quick retrofits on legacy equipment or new builds with standard 8.62 in length and 1.12 in width. Feature: Compliance and documentation. Business Impact: CE marked and RoHS compliant, with clear catalog references and installation notes for audit trails and regulatory readiness. Application: Supports quality management systems and supplier compliance programs in sectors such as automotive, food & beverage, and machinery.
