Eaton TB200-21 Panel Mount Terminal Block - CE RoHS
Part Number: TB200-21
Quick Summary
The Eaton TB200-21 panel mount terminal block offers reliable 21-pole connectivity for control panels and machine wiring. Engineers often grapple with dense wiring, limited space, and the need for compliant, maintainable blocks in harsh industrial environments. This unit is CE marked and RoHS compliant, supporting EU regulatory requirements while helping simplify procurement. With a barrier design and double-row configuration, it provides clear isolation between circuits, improving safety and troubleshooting. The TB200-21 integrates seamlessly into Wiring & Connectivity assemblies and complements standard panel hardware. By combining robust mechanical performance with straightforward installation, it delivers measurable reductions in wiring errors and maintenance downtime.
Product Information
Extended Description
TB200-21 Eaton: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800 V, 300 V, 30 A, Barrier, 21-pole, 6-32 TPI Screw, Black, Tin-plated brass terminal, Zinc-plated steel philslot screw
Product Name
Eaton Bussmann TB200 series panel mount terminal block connector
Catalog Number
TB200-21
UPC
051712274098
Product Length/Depth
9.94 in
Product Height
0.56 in
Product Width
1.12 in
Product Weight
4 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
Contact Manufacturer
Amperage Rating
30A
Voltage rating
300 V
Number Of Poles
21-pole
Type
Double row, barrier
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Feature: 21-pole, double-row barrier terminal block. Business Impact: Maximizes wiring density while maintaining circuit isolation, enabling compact control panels and easier fault tracing. Application: PLC I/O racks and machine control panels where space is at a premium. Feature: 30A, 300V electrical ratings. Business Impact: Supports typical automation circuits with reliable performance and safe margins. Application: Sensor, actuator, and logic-signal wiring in industrial automation. Feature: 4800V breakdown voltage. Business Impact: Superior dielectric withstand for surge immunity and protection against electrical transients. Application: High-energy control circuits and plant daisy-chains. Feature: Tin-plated brass terminals and zinc-plated steel philslot screws. Business Impact: Enhanced corrosion resistance and durable terminations for long service life in factory environments. Application: Harsh production floors and outdoor panels. Feature: Panel mount length 9.94 in, width 1.12 in, height 0.56 in, weight 4 lb. Business Impact: Predictable enclosure fit and straightforward mounting with minimal layout disruption. Application: Retrofit and new builds in standard enclosures. Feature: CE Marked, RoHS compliant. Business Impact: Regulatory compliance reduces audit risk and simplifies cross-border sourcing. Application: EU and global manufacturing deployments seeking compliant wiring solutions.
Get a Quick Quote for a Eaton TB200-21
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton TB200-21?
Enquire Now
FAQs
TB200-21 is designed for panel-mount installations with a 21-pole double-row barrier block. It fits standard industrial control panels and enclosure depths, and uses 6-32 TPI screws for common panel hardware.
TB200-21 is rated for 30A and 300V, with a breakdown voltage of 4800V. These ratings support typical automation circuits while maintaining a healthy safety margin in harsh environments.
Yes, TB200-21 is CE Marked and RoHS compliant, ensuring regulatory alignment for EU and global deployments and helping with supplier audits and compliance documentation.
The unit measures 9.94 inches in length, 1.12 inches in width, 0.56 inches in height, and weighs 4 pounds, making it suitable for compact control panels and retrofits.
You can download the Bussmann series catalog no. 1007 from Eaton’s site or related sources, including the full-line PDF catalogs and multimedia materials such as Bussmann Fuseology for additional context and reference.
