Eaton TB200-22 Panel Mount Terminal Block - CE RoHS
Part Number: TB200-22
Quick Summary
Eaton TB200-22 panel mount terminal block is a high-density 22-pole connector designed for robust control panel wiring. Engineers often struggle with space constraints, inconsistent terminations, and lengthy assembly times; this solution delivers a compact, reliable barrier-style block that speeds up wiring and improves reliability. With CE marking and RoHS compliance, it meets global safety and environmental requirements, while rugged tin-plated brass terminals and zinc-plated steel screws resist corrosion in demanding environments. The TB200-22 also aligns with 30A, 300V ratings and a dense 22-pole configuration, enabling scalable panel layouts. For procurement and maintenance teams, this translates into easier installation, consistent torque, and reduced field service interventions when wiring dense control architectures.
Product Information
Extended Description
TB200-22 Eaton: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800 V, 300 V, 30 A, Barrier, 22-pole, 6-32 TPI Screw, Black, Tin-plated brass terminal, Zinc-plated steel philslot screw
Product Name
Eaton Bussmann TB200 series panel mount terminal block connector
Catalog Number
TB200-22
UPC
051712556842
Product Length/Depth
10.37 in
Product Height
0.56 in
Product Width
1.12 in
Product Weight
4 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
Contact Manufacturer
Amperage Rating
30A
Voltage rating
300 V
Number Of Poles
22-pole
Type
Double row, barrier
Feature → Business Impact → Application: The TB200-22 uses a double-row barrier design to maximize channel density and reduce wiring harness length, delivering a measurable space-saving benefit in compact control panels and Machine Automation Controllers. This translates to lower enclosure footprint and faster panel wiring, particularly in automotive, packaging, and process lines where panel real estate is at a premium. Feature → Business Impact → Application: 22-pole configuration with barrier separation enhances circuit isolation, lowering risk of crosstalk and fault propagation; ideal for multi-line control circuits requiring clean, distinct terminations in food-and-beverage processing lines and CNC machines. Feature → Business Impact → Application: 6-32 TPI screw terminals with tin-plated brass contacts deliver reliable torque retention and corrosion resistance, reducing maintenance cycles and ensuring consistent electrical performance across shifts in harsh environments. Feature → Business Impact → Application: Rated 30A at 300V with a breakdown voltage of up to 4800V provides strong protection margins for motor starters, relays, and I/O blocks, supporting longer uptime in conveyors and material-handling systems. Feature → Business Impact → Application: Panel-mount integration with standard dimensions (10.37 in length, 1.12 in width, 0.56 in height) simplifies retrofits and new builds, enabling faster field installation and compatibility with existing Eaton Bussmann TB200 family components. Feature → Business Impact → Application: RoHS and CE compliance ensure regulatory alignment for global deployments, reducing compliance risk and allowing cross-border procurement and maintenance. These attributes, combined with a compact form factor, support a lower total cost of ownership through fewer spare parts and quicker service.
Get a Quick Quote for a Eaton TB200-22
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton TB200-22?
Enquire Now
FAQs
The TB200-22 is designed for panel mounting with a compact footprint. Use the included screws (6-32 TPI) to secure the block to the panel, ensure proper isolation between adjacent poles, and tighten to manufacturer torque specifications to maintain barrier integrity and prevent loose connections in vibration-prone environments.
It supports up to 30A at 300V with a breakdown voltage of up to 4800V, which provides a comfortable safety margin for typical control circuits, I/O interfaces, and small actuators. This ensures reliable operation in standard industrial control panels while maintaining insulation and protection against overvoltage.
Yes. The TB200-22 is a member of Eaton Bussmann TB200 series and shares form factor and barrier-oriented design principles, facilitating streamlined retrofits or expansions with compatible 22-pole, double-row configurations and barrier blocks.
The TB200-22 is CE marked and RoHS compliant, supporting global safety and environmental requirements. For broader certifications, consult the manufacturer documentation or catalog for any regional approvals needed for aerospace or specific machinery standards.
With tin-plated brass terminals and corrosion-resistant steel screws, the device provides durable termination over many mating cycles. The solid barrier design minimizes contact wear and reduces the likelihood of wiring faults, lowering maintenance costs and downtime in continuous-operation applications.
