Eaton TB200-23SP Panel Mount Terminal Block - CE RoHS
Part Number: TB200-23SP
Quick Summary
The Eaton TB200-23SP panel mount terminal block provides reliable 23-pole wiring in control panels. Engineers often contend with crowded panels where terminations loosen under vibration or corrosion, leading to intermittent faults. With CE Marked and RoHS compliant certifications, this block aligns with global electrical standards and reduces compliance risk. The 30 A, 300 V ratings support safe, scalable power distribution in industrial controls. Designed for dense installations, it delivers consistent torque, robust barrier isolation, and easy servicing for ongoing reliability in Wiring & Connectivity applications. By standardizing on the TB200-23SP, OEMs can streamline assembly, simplify maintenance, and improve traceability across multi-channel control systems.
Product Information
Extended Description
TB200-23SP Eaton: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800 V, 300 V, 30 A, 23-pole, Black, Tin-plated brass terminal, Zinc-plated steel SEMS philslot screw
Product Name
Eaton Bussmann TB200 series panel mount terminal block connector
Catalog Number
TB200-23SP
UPC
051712958103
Product Length/Depth
10.81 in
Product Height
0.56 in
Product Width
1.12 in
Product Weight
4 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
Contact Manufacturer
Amperage Rating
30A
Voltage rating
300 V
Number Of Poles
23-pole
Type
Barrier
Feature: 23-pole barrier construction provides dedicated, isolated conductors for each circuit—Business Impact: reduces cross-talk and wiring errors while improving fault isolation. Application: high-density control panels in packaging and process automation. The result is faster commissioning and lower troubleshooting time in complex machines. Feature: 30 A current rating and 300 V voltage rating enable safe, scalable power distribution across multiple loads—Business Impact: supports common-control architectures with room to grow, improving uptime and system resilience. Application: motor starters, sensors, and relay interfaces in industrial automation. Feature: Tin-plated brass terminals paired with zinc-plated steel SEMS philslot screws deliver corrosion resistance and secure terminations under vibration—Business Impact: minimizes maintenance cycles and rework, enhancing long-term reliability. Application: harsh plant environments where reliability matters. Feature: Panel mount design with a 10.81 in length and compact 1.12 in width reduces footprint while preserving accessibility—Business Impact: enables cleaner harness routing and faster assembly. Application: cabinet layouts with tight panning. Feature: CE Marked and RoHS compliant compliance provides regulatory confidence for global deployments—Business Impact: simplifies cross-border sourcing and accelerates time-to-market. Application: equipment certified for European and global markets. Additional Context: Breakdown voltage of 4800 V reinforces insulation performance in surge events, supporting robust protection in demanding installations.
