Eaton TB200-24 Panel Mount Terminal Block - CE RoHS
Part Number: TB200-24
Quick Summary
TB200-24 Panel Mount Terminal Block connects signals in control panels for 24 circuits. Engineers often grapple with dense wiring and unreliable terminations in tight cabinet spaces, which can lead to maintenance headaches and downtime. This device carries CE Marked and RoHS compliant certifications, with a 300 V rating at 30 A and a 24-pole, double-row barrier design that improves isolation and reliability. Its compact form factor and standard 6-32 TPI screws enable faster, scalable panel wiring. By choosing a certified, high-density terminal block, facilities can reduce wiring errors, streamline assembly, and simplify future upgrades while maintaining regulatory compliance.
Product Information
Extended Description
TB200-24 Eaton: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800 V, 300 V, 30 A, 24-pole, 6-32 TPI Screw, Black, Tin-plated brass terminal, Zinc-plated steel philslot screw
Product Name
Eaton Bussmann TB200 series panel mount terminal block connector
Catalog Number
TB200-24
UPC
051712272261
Product Length/Depth
11.25 in
Product Height
0.56 in
Product Width
1.12 in
Product Weight
4 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
Contact Manufacturer
Amperage Rating
30A
Voltage rating
300 V
Number Of Poles
24-pole
Type
Double row, barrier
24-pole, double-row barrier design enables high-density terminations without sacrificing isolation, reducing wiring complexity and potential cross-talk in noisy industrial environments. This supports cleaner wiring harnesses, faster panel assembly, and easier troubleshooting in PLC I/O racks and motor control centers. The 30 A at 300 V rating ensures compatibility with common control circuits while providing a safety margin for routine automation tasks, helping to minimize over-sizing and reduce waste. The 6-32 TPI screws with tin-plated brass terminals and zinc-plated steel philslot screws offer reliable terminations, corrosion resistance, and straightforward field servicing with standard tools. A breakdown voltage of 4800 V further enhances insulation tolerance for transient or surge conditions in demanding environments. CE Marked and RoHS compliant construction supports regulatory accuracy and supplier qualifications, aiding audits and procurement.
Get a Quick Quote for a Eaton TB200-24
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton TB200-24?
Enquire Now
FAQs
TB200-24 installs as a panel-mount block with a double-row barrier. Align the block, fasten with appropriate mounting hardware, and terminate each conductor using the 6-32 TPI screws. Maintain proper clearance between neighboring blocks for heat dissipation, and test continuity after each termination to prevent open circuits and ensure reliable operation in automation panels.
TB200-24 provides an amperage rating of 30 A and a voltage rating of 300 V, with 24 poles in a double-row barrier configuration. It is suitable for DC and AC control circuits typical in PLC I/O wiring and panel assemblies, offering a robust termination solution for distributed signals while maintaining insulation with a breakdown voltage up to 4800 V.
Yes. TB200-24 is CE Marked and RoHS compliant, ensuring regulatory alignment for industrial automation. Its tin-plated brass terminals and zinc-plated steel frame provide mechanical strength and corrosion resistance, supporting long-term reliability in factory environments with dust, humidity, and vibration. For applications requiring additional protection, ensure proper enclosures and cooling within the cabinet.
TB200-24 carries CE marking and RoHS compliance, signifying conformity with essential health, safety, and environmental requirements. These certifications simplify procurement for regulated industries, support audit readiness, and reduce risk when integrating with other EU-compliant components. The cataloged specifications also help engineers verify compatibility with existing control panels and safety standards.
Using TB200-24 delivers faster installation due to its dense 24-pole arrangement and standard screw terminals, reducing labor time per circuit. Its reliable termination, corrosion resistance, and high insulation tolerance minimize downtime from wiring faults, while CE RoHS compliance streamlines supplier qualification. Over time, these factors contribute to lower maintenance costs and improved panel reliability in automation projects.
