Eaton TB200-30 Panel Mount Terminal Block - CE RoHS
Part Number: TB200-30
Quick Summary
TB200-30 panel mount terminal block connector delivers compact, reliable 30-pole terminations for control panels. Engineers face dense wiring and risk of misrouting in large assemblies; barrier blocks and robust screws reduce errors. It carries CE marking and RoHS compliance, with additional certifications available from the manufacturer to support regulated environments. The product’s generous length and robust build support easy routing and long-term reliability, while standard 6-32 screws simplify installation across existing panel designs. By aligning with common automation wiring practices, TB200-30 helps reduce assembly time, simplify stocking, and improve overall electrical safety in industrial machinery and process control systems.
Product Information
Extended Description
TB200-30 Eaton: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800 V, 300 V, 30 A, 30-pole, 6-32 TPI Screw, Black, Tin-plated brass terminal, Zinc-plated steel philslot screw
Product Name
Eaton Bussmann TB200 series panel mount terminal block connector
Catalog Number
TB200-30
UPC
051712500630
Product Length/Depth
13.87 in
Product Height
0.56 in
Product Width
1.12 in
Product Weight
4.2 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
Contact Manufacturer
Amperage Rating
30A
Voltage rating
300 V
Number Of Poles
30-pole
Type
Double row, barrier
High-density 30-pole TB200-30 panel mount terminal block combines a double-row barrier with 6-32 TPI screws to deliver a compact footprint that frees panel space and reduces wiring complexity. This feature translates to faster harness assembly, easier labeling, and improved reliability under vibration in automated lines. The 30A, 300V rating covers typical control circuits, while breakdown voltage up to 4800V provides an added safety margin for transient events. Tin-plated brass terminals and zinc-plated steel philslot screws resist corrosion and wear in demanding environments, reducing maintenance costs and variance in termination quality. Compliance with CE and RoHS simplifies regulatory approvals, supporting multi-region deployments. The 13.87 in length and 4.2 lb weight offer predictable installation in medium-size panels, with compatibility for standard fasteners and common wiring practices.
Get a Quick Quote for a Eaton TB200-30
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton TB200-30?
Enquire Now
FAQs
TB200-30 is a panel-mount, double-row barrier terminal block designed for 30-pole terminations. It uses standard 6-32 TPI screws for secure termination and mounts to a control panel face or panel-mount envelope. The 13.87 in length helps align with common panel cutouts and simplifies wire routing, labeling, and field servicing in automated equipment.
TB200-30 provides a 30A amperage rating with a 300V voltage rating for typical automation circuits. It also features a breakdown voltage up to 4800V, offering a generous safety margin for transient events and switching surges common in industrial environments.
Yes. With 30 poles in a compact panel-mount double-row barrier design, TB200-30 enables dense wiring while maintaining safe isolation between circuits. This makes it ideal for machine control panels and process automation where space is at a premium and wiring clarity is critical.
TB200-30 is CE marked and RoHS compliant, aligning with European regulatory requirements for electrical equipment and restricted substances. For additional certifications, you may contact the manufacturer to confirm current approvals for your specific region or application.
The 30-pole, high-density arrangement reduces panel real estate and simplifies wiring harnesses, cutting assembly time and labor costs. Durable tin-plated brass terminals and corrosion-resistant screws minimize maintenance, while standard 6-32 screws ensure compatibility with existing tooling, supporting faster replacement and lower ongoing operating costs.
