Eaton TB200HB-04 terminal block connector - CE RoHS
Part Number: TB200HB-04
Quick Summary
TB200HB-04 terminal block connector is a reliable panel mount solution for wiring control panels and industrial equipment. Engineers often struggle with secure terminations in tight spaces, where vibration, heat, and high-voltage demands complicate reliability. The device carries CE marking and RoHS compliance, with additional certifications available from the manufacturer, ensuring regulatory alignment across global installations. Its four-pole, high-barrier design uses 6-32 TPI screws and tin-plated brass terminals for dependable, sealed terminations, even in dense wiring harnesses. This approach minimizes field rework while supporting scalable control wiring strategies for automation projects. By integrating with Eaton TB200 series, it delivers consistent performance and long-term cost savings in production environments.
Product Information
Extended Description
TB200HB-04 Eaton: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800 V, 600 V, 30 A, High barrier, 4-pole, 6-32 TPI Screw, Black, Tin-plated brass terminal, Zinc-plated steel philslot screw
Product Name
Eaton Bussmann TB200 series panel mount terminal block connector
Catalog Number
TB200HB-04
UPC
051712812429
Product Length/Depth
2.51 in
Product Height
0.75 in
Product Width
1.37 in
Product Weight
0.5 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
Contact Manufacturer
Amperage Rating
30A
Voltage rating
600 V
Number Of Poles
Four-pole
Type
Double row, high barrier
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Feature: Four-pole, high-barrier design with 6-32 TPI screws. Benefit: Delivers excellent circuit isolation and robust termination across multiple circuits, reducing crosstalk and field failures. Application: Ideal for dense wiring in control panels and automation enclosures. Feature: Electrical ratings of 30 A at 600 V with a 4800 V breakdown voltage. Benefit: Supports standard industrial loads while maintaining reliable insulation during transients and tests. Application: Machine control, power distribution, and panel wiring. Feature: Tin-plated brass terminals and zinc-plated steel philslot screws. Benefit: Superior corrosion resistance and durability in harsh environments, lowering maintenance costs. Application: Outdoor or dirty environments and long-life installations. Feature: Compact dimensions (2.51 in length, 1.37 in width, 0.75 in height) and weight of 0.5 lb. Benefit: Enables tighter panel layouts and easier installation with minimal footprint. Application: Modern control panels with space constraints. Feature: Compliance with CE and RoHS; Certifications available on request. Benefit: Simplifies regulatory approvals and global deployment, reducing project risk. Application: Global manufacturing and multi-site programs. Feature: Compatibility with TB200 series and standard 6-32 TPI screw terminations. Benefit: Streamlines spares management and replacement, lowering downtime. Application: Retrofit projects and new builds in automation facilities.
