Eaton TB200HB-05ST Panel Mount Terminal Block - 4800V
Part Number: TB200HB-05ST
Quick Summary
The Eaton TB200HB-05ST panel mount terminal block is designed for high-current, multi-pole connections in control panels and cabinets. Engineers often struggle with securing reliable wire terminations in tight spaces while maintaining insulation integrity. RoHS compliant and CE marked, this block supports global regulatory needs while delivering safe, long-lasting performance in demanding environments. Its five-pole, 30 A, 600 V rating enables compact, scalable wiring for automation systems, reducing install time and safeguarding device reliability across critical control applications.
Product Information
Extended Description
TB200HB-05ST Eaton: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800 V, 600 V, 30 A, High barrier, 5-pole, Black, Molded thermoplastic base, Stainless steel philslot screw
Product Name
Eaton Bussmann TB200 series panel mount terminal block connector
Catalog Number
TB200HB-05ST
UPC
051712636568
Product Length/Depth
2.94 in
Product Height
0.75 in
Product Width
1.37 in
Product Weight
0.6 lb
Warranty
Not Applicable
Compliances
RoHS Compliant CE Marked
Certifications
Contact Manufacturer
Amperage Rating
30A
Voltage rating
600 V
Number Of Poles
Five-pole
Type
High barrier
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Feature: High barrier molded thermoplastic base with stainless steel philslot screws. Business Impact: Provides superior insulation, chemical resistance, and secure, vibration-tolerant terminations, translating to fewer field failures. Application: Ideal for dense control panels in packaging lines and machine centers where reliability and space utilization matter. Feature: Five-pole design rated at 30 A and 600 V. Business Impact: Supports complex wiring schemes with robust load capacity, improving panel wiring efficiency and reducing component count. Application: Used in motor control, drives, and power distribution blocks within industrial automation systems. Feature: 4800 V breakdown voltage with standard operating voltage of 600 V. Business Impact: Enhances surge and insulation margin for safer operation in environments with high transient voltages. Application: Suitable for high-energy switching sections and signal-to-power interfaces. Feature: RoHS compliance and CE marking. Business Impact: Ensures regulatory readiness for global deployments and simplifies procurement across regions. Application: Global manufacturing lines requiring compliance documentation and traceable sourcing. Feature: Compact footprint and panel-mount form factor (2.94 in × 1.37 in × 0.75 in; 0.6 lb). Business Impact: Enables dense panel layouts, easier retrofits, and faster installation with predictable mounting footprints. Application: Enclosures with tight clearance where quick grounding and clean wiring are critical.
