Eaton TB200HB-09 TB200 Series Panel Mount Block - CE RoHS
Part Number: TB200HB-09
Quick Summary
The Eaton TB200HB-09 terminal block connector provides reliable panel wiring for control panels and electrical enclosures. Engineers often contend with tight spaces and vibration that can loosen connections in high-density assemblies. This device carries CE Marking and RoHS compliance, supporting European regulatory alignment and safer material usage. With a 9-pole, 30A at 600V rating and a high isolation barrier, it delivers secure, durable wiring in compact footprints. The tin-plated brass terminals and zinc-plated steel screws further enhance longevity in automation environments, while compatibility with the TB200 series streamlines procurement and maintenance for projects across manufacturing and process industries.
Product Information
Extended Description
TB200HB-09 Eaton: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800 V, 600 V, 30 A, High barrier, 9-pole, 6-32 TPI Screw, Black, Tin-plated brass terminal, Zinc-plated steel philslot screw
Product Name
Eaton Bussmann TB200 series panel mount terminal block connector
Catalog Number
TB200HB-09
UPC
051712812474
Product Length/Depth
4.69 in
Product Height
0.75 in
Product Width
1.37 in
Product Weight
0.6 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Amperage Rating
30A
Voltage rating
600 V
Number Of Poles
Nine-pole
Type
Double row, high barrier
Feature → Business Impact → Application: The TB200HB-09 employs a 9-pole, high-barrier panel mount design that delivers superior isolation between circuits, reducing cross-talk and fault propagation in dense switchgear and control panels. This translates to safer installations and lower fault investigation time for panel dissections in automation systems. Application: Ideal for servo drives, PLC I/O panels, and HMI enclosures where multiple low- to medium-power connections must be cleanly separated. Feature → Business Impact → Application: Rated at 30A and 600V, the terminal block supports robust power distribution without frequent reconfigurations, which reduces downtime and spare-part costs in line-side wiring. Application: Factory floor power distribution, machine control cabinets, and energy management panels. Feature → Business Impact → Application: Tin-plated brass terminals and zinc-plated steel philslot screws offer corrosion resistance and durable terminations, extending service life in demanding environments and lowering maintenance cycles. Application: Outdoor or humidity-prone panels, washdown zones, and long-life automation installations. Feature → Business Impact → Application: Compact dimensions (4.69 in L, 1.37 in W, 0.75 in H) enable high-density packing and simpler front-access wiring in tight control cabinets. Application: Automotive, packaging, and robotics panels with limited enclosure footprint. Feature → Business Impact → Application: 6-32 TPI screws provide compatibility with common wiring hardware, facilitating quick field termination and reducing training time for technicians. Application: Retrofit projects and new builds across automotive and industrial automation sectors. Feature → Business Impact → Application: CE Marked and RoHS compliant design ensures regulatory acceptance, traceable material compliance, and safer supply-chain practices. Application: European machine builders, process industries, and OEMs requiring regulatory alignment and risk mitigation. Feature → Business Impact → Application: High barrier and reliable performance support predictable maintenance schedules and improved uptime in mission-critical control systems. Application: CNC machines, robotic cells, and packaging lines where downtime is costly.
